XV-Z12000
Operation Manual
Adjustment b uttons
(", ', \, |)
For selecting menu items.
ENTER butto n
For setting items selected
or adjusted on the menu.
UNDO button
For undoing an operation or
returning to the default
settings.
Lens shift dial
Zoom knob
Focus ring
MENU button
For displaying adjustment
and setting screens.
RESIZE button
For switching the screen
size (SIDE BAR, SMART
STRETCH, etc.).
INPUT button
For switching input mode
1, 2, 3, 4 or 5.
ON button
For turning the power on.
STANDBY button
For putting the projector
into the standby mode.
Temperature warning
indicator
When the internal
temperature rises, this
indicator will illuminate
red.
Lamp indicator
Illuminates blue, indicating
normal function. Replace
the lamp when the
indicator illuminates red.
Power indicator
Illuminates red, when the
projector is in standby.
When the power is turned
on, this indicator will
illuminate blue.
Adjustment foot
Lens cap
Intake vent
Adjustment foot
Remote control
sensor
Projector (Front and Top View)
rt Names
A
ttac
h
in
g
an
d
removin
g
t
h
e lens ca
p
•
Press on the two buttons o
f
the lens ca
p
a
n
d
attac
h
it on t
h
e lens. T
h
en releas
e
t
h
e
b
uttons to lock it in place
.
•
Press on the two buttons o
f
the lens ca
p
a
nd remove it
f
rom the len
s.
In
t
h
i
s
o
perat
i
on manua
l,
the
ill
u
s
trat
i
on
a
n
d
t
he
s
c
reen
d
ispla
y
a
r
e
simpli
f
ied
fo
r exp
l
anat
i
on
,
a
nd may di
ff
er sli
g
htly
f
rom actual displa
y
.
