Sharp XV-Z12000 Service Manual

191
XV-Z12000
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
CABINET AND MECHANICAL PARTS
1 Not Available -Top Body Ass’y —
1-1 DBDYTA051WJ01 J Top Body Ass’y BX
1-1-1 Not Available -Top Body —
1-1-2 GCOVA1981CESA J Rear R/C Cover AE
1-1-3 HBDGS3153CESA J SHARP VISION Badge AQ
1-1-4 HiNDP5799CESA J Lens Warning Label AD
1-1-5 HiNDPA702WJSA J Operation Indication AG
1-1-6 PFILD0139CEZZ J Back Intake Filter AH
1-1-7 PMLT-0395CEZZ U Molt AX
1-1-8 PSPAH0708CEZZ J Spacer, x3 AC
1-1-9 PSPAH0709CEZZ J Spacer AB
1-1-10 PSLDMA158WJZZ J EMI Gasket AL
1-2 GCOVA1989CEKA J Lens Cover (Upper) AY
1-3 GCOVA1991CEZZ J LED Decoration AG
1-4 GDORT1097CEKC J Opration Door AR
1-5 LANGT9027CEFD J Door Shaft Angle A AF
1-6 LANGT9029CEFD J Door Shaft Angle B AG
1-7 LANGT9030CEFW U Connection Angle AE
1-8 LX-NZ3155CEFF J Speed Nut, x6 AF
1-9 MSPRD0087CEFW J Door Spring AD
1-10 NGERH3000CEFD J Door Gear AF
1-11 NSFTZ0177CEFW J Door Shaft AH
1-12 PDMPF0102CEZZ J Dumper AG
1-13 PKAi-0004GEZZ J Latch AK
1-14 PMLT-0397CEZZ J Lens Molt AE
1-15 PMLT-0398CEZZ J LED Molt, x2 AA
1-16 PSLDP3090CE00 J Rubber A AK
1-17 PSPAT0020CEZZ J Tefron Tape AD
1-18 QCNW-B859WJQZ J Connecting Cord(RE) AH
1-19 XBBSF20P05000 J Screw AA
1-20 XEBSD30P10000 J Screw, x8 AA
1-21 LHLDF1057CEZZ J IRIS DRIVE Unit Holder AB
2
Not Available - Bottom Body Ass’y —
2-1 DBDYUA052WJ01 J Bottom Body Ass’y BX
(XV-Z12000U)
2-1 DBDYUA052WJ03 J Bottom Body Ass’y BX
(XV-Z12000D/E/H/K/M)
2-1 DBDYUA052WJ04 J Bottom Body Ass’y BX
(XV-Z12000X)
2-1-1 Not Available - Bottom Body —
2-1-2 GCOVA1980CESA J Front R/C Cover AE
2-1-3 GCOVA2016CEKD J Exhaust Panel BG
2-1-4 HiNDP5781CESF J Hot Caution AE
2-1-7 LANGF2134CEFW J K Lock AE
2-1-8 LHLDZ2077CEKZ J K Lock Cover AD
2-1-9 LX-NZ3135CEFW J Insert Nut, x3 AD
2-1-10 PFILD0135CEZZ J Intake Filter A AM
2-1-11 PFILD0136CEZZ J Intake Filter B AG
2-1-12 PFILD0137CEZZ J Intake Filter AG
2-1-13 PMLT-0400CEZZ J Molt AD
2-1-14 PMLT-0403CEZZ J Molt AG
2-1-15 PSLDP3092CE00 J Rubber Button AG
2-1-16 HiNDPA665WJZZ J FCC Label (XV-Z12000U) AF
2-1-16 HiNDPA807WJZZ J FCC Label (XV-Z12000M)
2-1-17 HiNDPA662WJZZ J Model Label (XV-Z12000U) AK
2-1-17 HiNDPA741WJZZ J Model Label AK
(XV-Z12000D/E/H/K/M)
2-1-17 HiNDPA808WJZZ J Model Label (XV-Z12000X) AK
2-2 GCOVA1990CEKA J Lens Cover (Lower) AY
2-3 GCOVAA454WJKB J Hole Cover, x2 AB
2-4 GLEGP1020CEKE J Adjuster (R) AU
2-5 GLEGP3019CEKE J Adjuster (L) AU
2-6 HPNC-0469CESA J Intake Punching, x2 AK
2-7 PCOVUA023WJFW J Intake Cover AF
2-8 PDUC-0147CEKZ J Out Duct 1 AV
2-9 PDUC-0148CEKZ J Out Duct 2 AV
2-10 PDUC-0159CEKZ J Intake Duct AN
2-11 PSLDP3091CE00 J Rubber B AK
2-12 PSPAZ0428CEZZ J Duct Spacer AD
2-13 PSPAZ0443CEZZ J Duct Spacer AG
2-14 RH-HXA009WJQZ J Thermistor-A AM
2-15 XEBSD30P12000 J Screw, x12 AA
2-16 XEBSD40P16000 J Bottom Spacer, x7 AA
2-17 XEPSD30P06000 J Screw, x2 AA
2-18 GCOVAA586WJKA J Blank Cover AP
3 CCOVA1984CE05 J Lamp Door Ass’y BB
3-1 Not Available - Lamp Door —
3-2 HiNDPA680WJSA J Lamp Caution Label AH
3-3 LX-BZ1009CEFN J Screw, x2 AE
3-4 MSPRC0202CEFW J Door Spring, x2 AB
3-5 XRESJ30-06000 J E-Ring, x2 AA
4 CCOVA1985CE03 J Terminal Cover Ass’y AU
4-1 Not Available -Terminal Cover —
4-2 PCLiC1034CEKZ J Cover Clip AC
4-3 PCLiC1035CEKZ J Cover Clip Plun AC
4-4 SSAKA1109CEZZ J Cover Sack AH
5 CDUC-0154CE01 J HDDE Duct Ass’y BA
5-1 NFANR0072CE00 J Fan AX
5-2 Not Available - Power Duct A —
5-3 PDUC-0154CEKZ J Power Duct B AK
5-4 PMLT-0393CEZZ J Power Molt A AC
5-5 PMLT-0394CEZZ J Power Molt B AD
5-6 PSPAZ0445CEZZ J Fan Spacer AC
5-7 LHLDW1046CEZZ J Wire Holder AA
5-8 XEBSD30P12000 J Screw, x3 AA
6 Refer to Optics Mechanism Parts
7 Refer to Optics Mechanism Parts
8 Refer to Optics Mechanism Parts
9 DPNLH1107CE06 J Rear Body Ass’y BD
9-1 Not Available - Rear Body Ass’y —
9-2 HiNDPA257WJSA J Rear Indicator AL
9-3 LX-NZ3155CEFF J Speed Nut AF
10 Not Available - Lamp Panel Ass’y —
10-1 DPNLC1733CE06 J Lamp Panel Ass'y BB
10-1-1 Not Available - Lamp Panel —
10-1-2 HiNDP5848CESC J Inter Lock Indication AG
10-1-3 LX-NZ3135CEFW J Nut, 2 AD
10-2 LX-HZ3105CEFD J Screw AB
10-3 PSPAT0080CEZZ J Tefron Tape AB
10-4 QCNW-B857WJQZ J Door Switch AG
10-5 PCOVWA001CEKZ J Insulation Cover AC
11 CPCI-A008CE01 - PC I/F Unit Ass'y —
11-1 PSLDM3044CEFW J PC I/F Shield (Upper) AK
11-2 PSLDM3045CEFW J PC I/F Shield (Lower) AL
11-3 XBPSD30P06R00 J Screw AB
12 CSLDM3042CE02 J Shield Ass'y BC
12-1 Not Available - Power Unit Shield —
12-2 LHLDW1220CEZZ J Cover AD
12-3 LX-BZ3266CEFD J Screw, x3 AA
12-4 LX-LZ1014GE00 J Rivet AA
12-5 PGIDM0162CEKZ J Ventilating Guide B AD
12-6 PMLT-0399CEZZ J Power Shield Molt AG
12-7 PSHEG0033CEZZ J Radiator Sheet AV
12-8 RH-HXA010WJQZ J Thermistor-B AL
13 Not Available - Main Unit —
14 Not Available - Key Unit —
15 Not Available -R/C Receiver (Front) Unit —
16 Not Available - R/C Receiver (Rear) Unit —
17 Not Available - LED Unit —
18 JKNBZ1082CEKD J Lens Shift Knob AK
19 Not Available - IRIS DRIVE Unit —
21 LANGKA113WJFW J Lamp Socket Angle AF
22 LANGK0783CEFW J Color Wheel Fan Angle AH
23 LANGK0786CEFW J Fan Angle AH
24 LANGQ5725CEFW J R/C Receiver (Front) Fixing AF
Angle
