Sharp XV-Z12000 Service Manual

179
XV-Z12000
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
DUNTKC171DE01
MAIN UNIT(Continued)
R2808 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2809 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2817 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2818 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2819 VRN-CY1JF153DY J 15k 1/16W Metal Film AA
R2821 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2822 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2825 VRN-CY1JF153DY J 15k 1/16W Metal Film AA
R2832 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2847 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
R2849 VRS-TX2HF120JY J 12 1/2W Metal Oxide AB
R2850 VRS-TX2HF120JY J 12 1/2W Metal Oxide AB
R2851 VRS-TX2HF1R0JY J 1 1/2W Metal Oxide AB
R2853 VRS-TX2HF5R6JY J 5.6 1/2W Metal Oxide AB
R2854 VRS-TW2ED1R2JY J 1.2 1/4W Metal Oxide AB
R2855 VRS-TW2ED1R2JY J 1.2 1/4W Metal Oxide AB
R2856 VRS-TX2HF1R0JY J 1 1/2W Metal Oxide AB
R2857 VRS-TX2HF5R6JY J 5.6 1/2W Metal Oxide AB
R2860 VRS-TX2HF000JY J 00 1/2W Metal Oxide AB
R2862 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2864 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2865 VRN-CY1JF274DY J 270k 1/16W Metal Film AA
R2866 VRN-CY1JF114DY J 110k 1/16W Metal Film AA
R2869 VRN-CY1JF183DY J 18k 1/16W Metal Film AA
R2870 VRN-CY1JF912DY J 9.1k 1/16W Metal Film AA
R2873 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2875 VRN-CY1JF222DY J 2.2k 1/16W Metal Film AB
R2876 VRN-CY1JF120DY J 12 1/16W Metal Film AA
R2877 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2878 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2879 VRS-TW2ED2R2JY J 2.2 1/4W Metal Oxide AA
R2881 VRS-TV1JD222JY J 2.2k 1/16W Metal Oxide AA
R2882 VRS-TV1JD3R9JY J 3.9 1/16W Metal Oxide AA
R2883 VRS-TW2ED2R2JY J 2.2 1/4W Metal Oxide AA
R2886 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2887 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2891 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2893 VRS-TV1JD272JY J 2.7k 1/16W Metal Oxide AA
R2894 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2896 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2898 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2904 VRS-CY1JF000JY J 00 1/16W Metal Oxide AA
R2912 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2913 VRS-CY1JF000JY J 00 1/16W Metal Oxide AA
R2915 VRS-TX2HF821JY J 820 1/2W Metal Oxide AB
R2916 VRS-TX2HF821JY J 820 1/2W Metal Oxide AB
R2917 VRS-CY1JF181JY J 180 1/16W Metal Oxide AA
R2918 VRS-CY1JF181JY J 180 1/16W Metal Oxide AA
R2919 VRS-CY1JF000JY J 00 1/16W Metal Oxide AA
R2920 VRS-CY1JF000JY J 00 1/16W Metal Oxide AA
R2924 VRS-TX2HF2R2JY J 2.2 1/2W Metal Oxide AB
R2926 VRN-CY1JF202DY J 2k 1/16W Metal Film AA
R2927 VRN-CY1JF222DY J 2.2k 1/16W Metal Film AB
R2928 VRN-CY1JF750DY J 75 1/16W Metal Film AA
R2929 VRS-TX2HF1R0JY J 1 1/2W Metal Oxide AB
R2930 VRN-CY1JF682DY J 6.8k 1/16W Metal Film AB
R2931 VRN-CY1JF201DY J 200 1/16W Metal Film AA
R2932 VRN-CY1JF102DY J 1k 1/16W Metal Film AA
R2933 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2935 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
R2936 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3502 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3503 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R3504 VRS-CY1JF152JY J 1.5k 1/16W Metal Oxide AA
R3505 VRS-CY1JF431JY J 430 1/16W Metal Oxide AA
R3506 VRS-CY1JF911FY J 910 1/16W Metal Oxide AA
R3507 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R3508 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R3509 VRS-CY1JF561FY J 560 1/16W Metal Oxide AA
R3510 VRS-CY1JF182JY J 1.8k 1/16W Metal Oxide AA
R3511 VRS-CY1JF202JY J 2k 1/16W Metal Oxide AA
R3512 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3513 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3514 VRS-CY1JF821JY J 820 1/16W Metal Oxide AA
R3515 VRS-CY1JF911JY J 910 1/16W Metal Oxide AB
R3517 VRS-CY1JF272JY J 2.7k 1/16W Metal Oxide AA
R3518 VRS-CY1JF202JY J 2k 1/16W Metal Oxide AA
R3519 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3520 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3521 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3522 VRS-CY1JF391JY J 390 1/16W Metal Oxide AA
R3523 VRS-CY1JF181JY J 180 1/16W Metal Oxide AA
R3524 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3525 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3526 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R3527 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R3528 VRS-TX2HF2R2JY J 2.2 1/2W Metal Oxide AB
R3529 VRS-TV1JD2R2JY J 2.2 1/16W Metal Oxide AA
R3530 VRS-CY1JF000JY J 00 1/16W Metal Oxide AA
R3531 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R3532 VRS-CY1JF000JY J 00 1/16W Metal Oxide AA
R3533 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R3534 VRS-CY1JF224JY J 220k 1/16W Metal Oxide AA
R3535 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3536 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R3537 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R3538 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R3539 VRS-CY1JF182JY J 1.8k 1/16W Metal Oxide AA
R3540 VRS-CY1JF182JY J 1.8k 1/16W Metal Oxide AA
R3541 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R3543 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3546 VRS-CY1JF000JY J 00 1/16W Metal Oxide AA
R3547 VRS-CY1JF000JY J 00 1/16W Metal Oxide AA
R3548 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R3549 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R3561 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3563 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R3564 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R3570 VRS-TW2ED391JY J 390 1/4W Metal Oxide AA
R3572 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R3573 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R3575 VRS-TW2ED391JY J 390 1/4W Metal Oxide AA
R3577 VRS-TW2ED391JY J 390 1/4W Metal Oxide AA
R3580 VRS-TX2HF1R0JY J 1 1/2W Metal Oxide AB
R3581 VRS-TX2HF1R0JY J 1 1/2W Metal Oxide AB
R3582 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R3586 VRS-CY1JF510FY J 51 1/16W Metal Oxide AA
R3587 VRS-CY1JF750JY J 75 1/16W Metal Oxide AA
R3588 VRS-CY1JF510FY J 51 1/16W Metal Oxide AA
R3589 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3590 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3591 VRS-CY1JF391JY J 390 1/16W Metal Oxide AA
R3592 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
R3593 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3594 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R3595 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R3596 VRS-CY1JF391JY J 390 1/16W Metal Oxide AA
R3597 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
CONTROL
SW2002QSW-K0065GEZZY J Key Switch AD
MISCELLANEOUS PARTS
FB2003 RBLN-0059CEZZY J Ferrite Bead AB
FB2004 RBLN-0059CEZZY J Ferrite Bead AB
FB2005 RBLN-0059CEZZY J Ferrite Bead AB
FB2501 RBLN-0060TAZZY J Ferrite Bead AB
FB2502 RBLN-0060TAZZY J Ferrite Bead AB
FB2503 RBLN-0060TAZZY J Ferrite Bead AB
FB2504 RBLN-0060TAZZY J Ferrite Bead AB
FB2516 RBLN-0061TAZZY J Ferrite Bead AD
FB2517 RBLN-0061TAZZY J Ferrite Bead AD
FB2801 RBLN-0059CEZZY J Ferrite Bead AB
FB2802 RBLN-0064TAZZY J Ferrite Bead AB
FB2803 RBLN-0064TAZZY J Ferrite Bead AB
FB2804 RBLN-0064TAZZY J Ferrite Bead AB
FB2805 RBLN-0064TAZZY J Ferrite Bead AB
FB2809 RBLN-0058TAZZY J Ferrite Bead AC
