Sharp XV-Z12000 Service Manual

178
XV-Z12000
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
R2577 VRS-CY1JF220JY J 22 1/16W Metal Oxide AA
R2579 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2580 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2581 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2582 VRS-CY1JF220JY J 22 1/16W Metal Oxide AA
R2585 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2588 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2592 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2593 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2594 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2595 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2599 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2603 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2615 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R2640 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2641 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2642 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2644 VRS-TW2ED391JY J 390 1/4W Metal Oxide AA
R2646 VRS-CY1JF680JY J 68 1/16W Metal Oxide AA
R2647 VRS-TW2ED391JY J 390 1/4W Metal Oxide AA
R2649 VRS-CY1JF680JY J 68 1/16W Metal Oxide AA
R2650 VRS-TW2ED391JY J 390 1/4W Metal Oxide AA
R2652 VRS-CY1JF680JY J 68 1/16W Metal Oxide AA
R2653 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2656 VRS-TW2ED391JY J 390 1/4W Metal Oxide AA
R2663 VRS-CY1JF680JY J 68 1/16W Metal Oxide AA
R2665 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2666 VRS-CY1JF271JY J 270 1/16W Metal Oxide AA
R2668 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2669 VRS-CY1JF330JY J 33 1/16W Metal Oxide AA
R2670 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
R2671 VRS-CY1JF183JY J 18k 1/16W Metal Oxide AA
R2672 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2673 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2674 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R2675 VRS-CY1JF183JY J 18k 1/16W Metal Oxide AA
R2676 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2677 VRS-CY1JF391JY J 390 1/16W Metal Oxide AA
R2678 VRS-CY1JF391JY J 390 1/16W Metal Oxide AA
R2679 VRS-CY1JF153JY J 15k 1/16W Metal Oxide AA
R2681 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R2682 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R2683 VRS-CY1JF391JY J 390 1/16W Metal Oxide AA
R2684 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R2685 VRS-CY1JF391JY J 390 1/16W Metal Oxide AA
R2686 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2687 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2688 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R2689 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2690 VRS-CY1JF271JY J 270 1/16W Metal Oxide AA
R2691 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2692 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R2693 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R2697 VRS-CY1JF153JY J 15k 1/16W Metal Oxide AA
R2700 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2703 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R2704 VRS-CY1JF330JY J 33 1/16W Metal Oxide AA
R2705 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
R2706 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2707 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2708 VRS-CY1JF330JY J 33 1/16W Metal Oxide AA
R2709 VRS-CY1JF330JY J 33 1/16W Metal Oxide AA
R2710 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R2711 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
R2712 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
R2714 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R2715 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R2716 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R2717 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2718 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2719 VRS-CH1JF000JY J 00 1/16W Metal Oxide AA
R2803 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2804 VRS-CY1JF182JY J 1.8k 1/16W Metal Oxide AA
R2805 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R2806 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2807 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
DUNTKC171DE01
MAIN UNIT(Continued)
C3576 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3577 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3580 VCEAPF1CW476MY J 47 16V Electrolytic AC
C3581 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3582 VCEAPF0JW107MY J 100 6.3V Electrolytic AC
C3583 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
RESISTORS
R2010 VRS-TV1JD3R9JY J 3.9 1/16W Metal Oxide AA
R2011 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R2012 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2013 VRS-CY1JF154JY J 150k 1/16W Metal Oxide AA
R2018 VRS-CY1JF153JY J 15k 1/16W Metal Oxide AA
R2025 VRS-CH1JF101JY J 100 1/16W Metal Oxide AA
R2028 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R2029 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R2031 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2038 VRS-CH1JF101JY J 100 1/16W Metal Oxide AA
R2039 VRS-CY1JF682JY J 6.8k 1/16W Metal Oxide AA
R2040 VRS-CH1JF103JY J 10k 1/16W Metal Oxide AA
R2041 VRS-CH1JF101JY J 100 1/16W Metal Oxide AA
R2043 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R2047 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R2049 VRS-CH1JF101JY J 100 1/16W Metal Oxide AA
R2050 VRS-CH1JF101JY J 100 1/16W Metal Oxide AA
R2051 VRS-CH1JF100JY J 10 1/16W Metal Oxide AA
R2053 VRS-CH1JF101JY J 100 1/16W Metal Oxide AA
R2054 VRS-CH1JF100JY J 10 1/16W Metal Oxide AA
R2056 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R2057 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R2058 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R2060 VRS-CJ1JF151JY J 150 1/16W Metal Oxide AA
R2061 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2066 VRS-CH1JF100JY J 10 1/16W Metal Oxide AA
R2067 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R2068 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2070 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2071 VRS-CH1JF103JY J 10k 1/16W Metal Oxide AA
R2072 VRS-CJ1JF103JY J 10k 1/16W Metal Oxide AA
R2073 VRS-CH1JF823JY J 82k 1/16W Metal Oxide AA
R2074 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R2075 VRS-CH1JF102JY J 1k 1/16W Metal Oxide AA
R2076 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2078 VRS-CH1JF823JY J 82k 1/16W Metal Oxide AA
R2081 VRS-CY1JF100JY J 10 1/16W Metal Oxide AA
R2501 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R2502 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R2503 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2504 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2505 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R2506 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2507 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2512 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R2513 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R2521 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R2522 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R2523 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R2531 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2533 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2535 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2536 VRS-CY1JF220JY J 22 1/16W Metal Oxide AA
R2537 VRS-CY1JF220JY J 22 1/16W Metal Oxide AA
R2538 VRS-CY1JF220JY J 22 1/16W Metal Oxide AA
R2539 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2540 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2541 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2542 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2559 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2571 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2572 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2575 VRS-CY1JF220JY J 22 1/16W Metal Oxide AA
R2576 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
