Sharp XV-Z12000 Service Manual

177
XV-Z12000
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
DUNTKC171DE01
MAIN UNIT(Continued)
C2519 VCKYTV1CB105KY J 1 16V Ceramic AC
C2520 VCKYTV1CB105KY J 1 16V Ceramic AC
C2521 VCKYTV1CB105KY J 1 16V Ceramic AC
C2526 VCEAPF1HW105MY J 1 50V Electrolytic AB
C2528 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2529 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2530 VCEAPF1HW105MY J 1 50V Electrolytic AB
C2531 VCEAPF1HW105MY J 1 50V Electrolytic AB
C2537 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2538 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2539 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2543 VCEAPF1CW107MY J 100 16V Electrolytic AC
C2544 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2568 VCEAPF1CW476MY J 47 16V Electrolytic AC
C2572 VCEAPF0JW227MY J 220 6.3V Electrolytic AD
C2573 VCEAPF0JW227MY J 220 6.3V Electrolytic AD
C2574 VCEAPF0JW227MY J 220 6.3V Electrolytic AD
C2576 VCEAPF0JW227MY J 220 6.3V Electrolytic AD
C2577 VCEAPF0JW227MY J 220 6.3V Electrolytic AD
C2578 VCEAPF0JW227MY J 220 6.3V Electrolytic AD
C2586 VCEAPF0JW227MY J 220 6.3V Electrolytic AD
C2587 VCEAPF0JW227MY J 220 6.3V Electrolytic AD
C2588 VCCCCY1HH330JY J 33p 50V Ceramic AA
C2589 VCEAPF0JW226MY J 22 6.3V Electrolytic AB
C2590 VCE9PF1CW106MY J 10 16V Elect.(N,P) AC
C2591 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2592 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2593 VCE9PF1CW106MY J 10 16V Elect.(N,P) AC
C2594 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2595 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2596 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2597 VCCCCY1HH330JY J 33p 50V Ceramic AA
C2598 VCE9PF1CW106MY J 10 16V Elect.(N,P) AC
C2599 VCE9PF1CW106MY J 10 16V Elect.(N,P) AC
C2600 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2601 VCKYCY1HB472KY J 4700p 50V Ceramic AA
C2602 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2603 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2604 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2605 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2606 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2607 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2803 VCCCCY1HH101JY J 100p 50V Ceramic AA
C2805 VCCCCY1HH101JY J 100p 50V Ceramic AA
C2812 VCKYCY1CB104KY J 0.1 16V Ceramic AB
C2815 VCKYCY1CB104KY J 0.1 16V Ceramic AB
C2818 VCEAPF1CW226MY J 22 16V Electrolytic AB
C2822 VCEAPF1CW107MY J 100 16V Electrolytic AC
C2823 VCEAPF1CW107MY J 100 16V Electrolytic AC
C2824 VCEAPF1CW107MY J 100 16V Electrolytic AC
C2825 VCKYTV1EB104KY J 0.1 25V Ceramic AB
C2826 VCEAPF1EW336MY J 33 25V Electrolytic AD
C2827 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2828 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2829 VCEAPF1CN107MY J 100 16V Electrolytic AD
C2830 VCKYTV1EB104KY J 0.1 25V Ceramic AB
C2832 VCEAPF1CN107MY J 100 16V Electrolytic AD
C2833 VCKYTV1EB104KY J 0.1 25V Ceramic AB
C2834 VCEAPF0JW227MY J 220 6.3V Electrolytic AD
C2835 VCEAPF1CW106MY J 10 16V Electrolytic AB
C2836 VCEAPF1CN107MY J 100 16V Electrolytic AD
C2837 VCEAPF1EW336MY J 33 25V Electrolytic AD
C2838 VCKYCY1CB104KY J 0.1 16V Ceramic AB
C2839 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2841 VCKYCY1CB104KY J 0.1 16V Ceramic AB
C2842 VCEAPF0JW336MY J 33 6.3V Electrolytic AB
C2844 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2846 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2849 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2852 VCKYCY1CB104KY J 0.1 16V Ceramic AB
C2854 VCKYCY1CB104KY J 0.1 16V Ceramic AB
C2856 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2857 VCEAPF1CN107MY J 100 16V Electrolytic AD
C2859 VCEAPF1CW107MY J 100 16V Electrolytic AC
C2860 VCEAPF1CW107MY J 100 16V Electrolytic AC
C2861 VCEAPX1CW477MY J 470 16V Electrolytic AE
C2862 VCEAPX1CW477MY J 470 16V Electrolytic AE
C2869 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2870 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2871 VCAAPC1AJ336MY J 33 10V Electrolytic AG
C2872 VCEAPF0JW107MY J 100 6.3V Electrolytic AC
C2873 VCEAPF0JW107MY J 100 6.3V Electrolytic AC
C2874 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2875 VCEAPF1CW107MY J 100 16V Electrolytic AC
C2876 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2877 VCEAPF1CW107MY J 100 16V Electrolytic AC
C2878 VCEAPF1HW475MY J 4.7 50V Electrolytic AC
C2879 VCEAPF1HW475MY J 4.7 50V Electrolytic AC
C3505 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3506 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C3507 VCCCCY1HH120JY J 12p 50V Ceramic AA
C3508 VCCCCY1HH100DY J 10p 50V Ceramic AA
C3510 VCCCCY1HH6R0DY J 6.0p 50V Ceramic AA
C3511 VCCCCY1HH120JY J 12p 50V Ceramic AA
C3512 VCCCCY1HH270JY J 27p 50V Ceramic AA
C3513 VCCCCY1HH270JY J 27p 50V Ceramic AA
C3514 VCEAPF1CW106MY J 10 16V Electrolytic AB
C3515 VCCCCY1HH270JY J 27p 50V Ceramic AA
C3516 VCEAPF0JW226MY J 22 6.3V Electrolytic AB
C3517 VCCCCY1HH270JY J 27p 50V Ceramic AA
C3518 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C3520 VCEAPF0JW107MY J 100 6.3V Electrolytic AC
C3521 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3522 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3523 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3524 VCEAPF1HW105MY J 1 50V Electrolytic AB
C3525 VCEAPF0JW226MY J 22 6.3V Electrolytic AB
C3526 VCEAPF0JW226MY J 22 6.3V Electrolytic AB
C3527 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3528 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3529 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3530 VCEAPF1CW106MY J 10 16V Electrolytic AB
C3531 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3532 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3533 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3534 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3535 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3536 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3537 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3538 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3539 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3540 VCEAPF1HW105MY J 1 50V Electrolytic AB
C3541 VCCCCY1HH471JY J 470p 50V Ceramic AA
C3543 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3545 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3546 VCEAPF1HW474MY J 0.47 50V Electrolytic AC
C3547 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C3548 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3549 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3550 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3551 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3552 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3553 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3554 VCCCCY1HH270JY J 27p 50V Ceramic AA
C3555 VCCCCY1HH220JY J 22p 50V Ceramic AA
C3556 VCEAPF0JW226MY J 22 6.3V Electrolytic AB
C3557 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3558 VCCCCY1HH391JY J 390p 50V Ceramic AB
C3559 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3563 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3565 VCEAPF1CW106MY J 10 16V Electrolytic AB
C3567 VCEAPF1CW107MY J 100 16V Electrolytic AC
C3570 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3571 VCEAPF0JW227MY J 220 6.3V Electrolytic AD
C3572 VCEAPF0JW227MY J 220 6.3V Electrolytic AD
C3573 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C3574 VCEAPF0JW227MY J 220 6.3V Electrolytic AD
C3575 VCEAPF0JW227MY J 220 6.3V Electrolytic AD
