RECEIVING
ORIENTATION IMAGE
1
st
Fuse in Power Inlet
2nd Fuse in
Holder
SCO5W
-2
Chamber Gasket
Chamber HEPA
Filter
Door Latch
Viewing Door (Glass)
Chamber Door
Back of Unit
CO
2
In Ports
Chamber Door
Handle
Back of Unit
Fill
Water Jacket Ports
Siphon
Viewing Door Knob
Anode
Access Port
Door Gasket
CO
2
Sample
and Data Ports
Control Panel
Side of Unit
Shelf-Standard
Mounting Rail
