57 | Page
UNIT SPECIFICATIONS
The SCO5W-2 Incubator is a 220 – 240 volt unit. Please refer to the incubator data plate for
individual electrical specifications.
Technical data specified applies to units with standard equipment at an ambient temperature of 25°C
and at nominal voltage. The temperatures specified are determined in accordance to factory
standard following DIN 12880 respecting the recommended wall clearances of 10% of the height,
width, and depth of the inner chamber. All indications are average values, typical for units produced
in the series. We reserve the right to alter technical specifications at all times.
WEIGHT
Shipping Unit
284 lb / 129 kg 254.0 lb / 115.2 kg
DIMENSIONS
Unit Body
In inches
Exterior W × D × H Interior W × D × H
26.0 x 25.5 x 40.3 19.3 x 19.8 x 23.0
In millimeters
Exterior W × D × H Interior W × D × H
661 x 648 x 1024 490 x 503 x 584
Access Port
Inner Diameter
1.3 in 33 mm
