INSTALLATION
CONNECT TO THE CO
2
SUPPLY
Note: See page 9 for CO
2
supply requirements.
Connect the supply source to the incubator.
If connecting a second supply cylinder, do so now.
Do not initiate a flow of CO
2
to the incubator at this time.
End of Procedure
CO
2
to Chamber
“IN”
Connects to 3/16”
(4.76mm) ID Tubing
Single Source
Dual Source
“IN”
Optional Tubing Kit
with Inline HEPA Filter
Dual-Stage CO
2
Pressure Regulator
