17Installation manual – NewMotion Business Pro & Lite 2.1 / 2.2 - 091NMEN13

12 . Twist the socket lid counterclockwise and pull it from the cover (see  gure 11 1 2 ).

13 . Pull the cover from the casing to open the charge point and access the internal components (see  gure 11 3 ).

14 . Check if all the connected wiring and internal components of the product are properly fastened.

5 . 4 . Mounting

Check the applicable method of installation and continue to the assigned chapter.

Wall mount Pavement mount Soil mount

e r t

Go to chapter 5 . 4 . 1 . Wall mount Go to chapter 5 . 4 . 2 . Pavement mount Go to chapter 5 . 4 . 3 . Soil mount
