33Installation manual – NewMotion Home Advanced 2.1 / 2.2 - 071NMEN13
M4 × 20 mm
T20
D F
5. Place the grey lid slightly tilted counterclockwise into the socket hole on the cover (see gure 48).
NOTICE In case you have installed the tethered charging cable, place the dummy socket instead.
6. Secure the grey lid to the cover by hand with a provided M4 × 20 mm Torx bolt, using a T20 screwdriver (see gure
49).
6 CAUTION
Do not use an electrical screwdriver to secure the bolts, this can damage the lid, cover or casing.
