32Installation manual – NewMotion Home Advanced 2.1 / 2.2 - 071NMEN13

5 . 8 . Finishing installation

1 . NOTICE If there is no tethered cable installed, insert the black grommet in the front cable inlet (see  gure 46 ).

M4 × 12 mm

T20

2 . Ensure that the rubber seal on the edge of the casing is properly in place.

3 . Place the cover on the casing (see  gure 47 1 ).

4 . Secure the cover to the casing by hand with 6 provided M4 × 12 mm Torx bolts, using a T20 screwdriver (see  gure

47 2 ).

6 CAUTION

Do not use an electrical screwdriver to secure the bolts, this can damage the cover or casing.
