1-17
13. Location: Left hand side ROPS.
WARNING:
Always turn the key to OFF
position and remove it, before performing any
intervention or service on the tractor; always
refer to the Operator’s manual for specific
information.
WARNING:
Always wear the seat belt when
the tractor is equipped with a ROPS with raised
locking position.
Part No. 390199480
14. Location: Left hand side ROPS.
WARNING:
To avoid serious injury, always
raise the ROPS and lock it, when you drive or
operate the tractor.
Part No. 390198011
15. Location: Right hand side ROPS.
WARNING:
Pull only from the drawbar. Always
use the
drawbar or the lower links in the
lowered position, when performing pull-type
work.
Part No. 390199600
