SECTION 3 – LUBRICATION AND MAINTENANCE
3-11
AIR CLEANER
The air cleaner (1) in Figure 3-12, is accessed by
opening the tractor hood.
The air cleaner assembly contains two elements:
an outer (primary) element, and an inner (safety)
element.
To remove the primary element, release the clips
(2) in Figure 3-12, on the end cap.
Remove the end cap from the air cleaner body to
expose the primary element (3) in Figure 3-13.
Figure 3-12
Figure 3-13
