 SECTION 2 – OPERATION 
2-9
LIGHTING
Your tractor equipped with:
• Headlights (1) in Figure 2-13.
• Side and Front Position Lights (2) in Figure
2-14.
• Flasher Warning Lights / Turn Signals (3) in
Figure 2-14.
 Side and Taillights / Brake Lights (4) in Figure
2-15.
 Flasher Warning Lights / Turn Signals (5) in
Figure 2-15.
1

Figure 2-13
3
2
Figure 2-14
5
4
Figure 2-15
