WHEEL TREAD SETTINGS
NOTE: Tread settings are measured from center of tire to center of tire.
Front Wheel Settings
Tire Type Setting Note
AG 8 - 16 1,151 mm Not Adjustable
TURF 27 x 10.5 - 15 1,305 mm Not Adjustable
Large Turf (FD) 8 - 16 1,151 mm Not Adjustable
Industrial (R4) 10-16.5 1,252 mm Not Adjustable
IMPORTANT:
Never attempt to widen the tread setting by reversing the front wheels on a front-wheel
drive system.
NOTE:
Torque front wheel bolts to 175 N
·
m.
Rear Wheel Settings
Tire Type MIN (DISH IN) MAX (DISH OUT) NO. OF POSITION
AG 13.6 - 24 1,127 mm 1,477 mm 7
TURF 475/65D20 1,269 mm 1,285 mm 1
Large Turf (FD) 13.6 - 28 1,127 mm 1,477 mm 7
Industrial (R4) 17.5L - 24 1,123 mm 1,331 mm 6
NOTE:
Torque rear wheel bolts to 175 N·m. Torque rim to disc bolts to 230 N·m
