 SECTION 1 – GENERAL INFORMATION AND SAFETY

1-20

Turn Signal
PART NO: 390380960
LOCATION: Left Side
of Dash
Road Light Switch
PART NO: 390380791
LOCATION: Left Side
of Dash
Road Light High
Beam Switch
PART NO: 390230810
LOCATION: Left Side
of Dash
Throttle
PART NO: 390430290
LOCATION: Right Side
of Dash
Hazard Flasher
Light Switch
PART NO: 390380770
LOCATION: Right Side
of Dash
Hydraulic Manifold
Operation
(See Operator’s Manual)
PART NO: SBA390198320
LOCATION: Top of
Hydraulic Manifold Block
Horn Switch
PART NO: 390230970
LOCATION: Right Side
of Dash
HST Hi / Lo Speed
Control Switch
PART NO: 390174560
LOCATION: Left Side
of Dash
