Shihlin electric SS2-021 Series User Manual

129
Appendix 1 Parameter list
Parameter List
Parameter
numberʳ
Nameʳ Setting range
Minimum
setting unit
Default valueʳ
User setting
value
Reference
page
P. 0 Torque boostʳ
0~30% 0.1% (Note) P42
P. 1 Maximum frequencyʳ
0~120Hz 0.01Hz 120Hz P43
P. 2 Minimum frequencyʳ
0~120Hz 0.01Hz 0Hz P43
P. 3 Base frequencyʳ
0~650Hz 0.01Hz
50Hz/60Hz
(Note)
P44
P. 4 Speed 1 (high speed)ʳ
0~650Hz 0.01Hz 60Hz P45
P. 5 Speed 2 (middle speed)ʳ
0~650Hz 0.01Hz 30Hz P45
P. 6 Speed 3 (low speed)ʳ
0~650Hz 0.01Hz 10Hz P45
5s˄3.7KW and below˅
P. 7 Acceleration time
0~360.00s/
0~3600.0s
0.01s/0.1s
10s˄5.5KW˅
P46
5s˄3.7KW and below˅
P. 8 Deceleration time
0~360.00s/
0~3600.0s
0.1s/0.01s
10s˄5.5KW˅
P46
P. 9
Electronic thermal relay
capacityʳ
0~500A 0.01A 0 P48
P.10
DC injection brake
operation frequencyʳ
0~120Hz 0.01Hz 3Hz P48
P. 11
DC injection brake
operation timeʳ
0~60 0.1 0.5
P48
P.12 DC injection brake voltageʳ
0~30% 0.1% 4% P48
P.13 Starting frequencyʳ
0~60Hz 0.01Hz 0.5Hz P49
P.14 Load pattern selectionʳ
0~13 1 0 P50
P.15 JOG frequency
0~650Hz 0.01Hz 5Hz P53
P.16
JOG acceleration /
deceleration time
0~360.00s/
0~3600.0s
0.1s/0.01s 0.5s P53
P.17
Input signal across terminal
4-5 selection
0~2 1 0 P78
P.18
High-speed maximum
frequencyʳ
120~650Hz 0.01Hz 120Hz P43
P.19 Base frequency voltageʳ
0~1000V, 9999 0.1V 9999 P44
P.20
Acceleration/deceleration
reference frequencyʳ
1~650Hz 0.01Hz
50Hz/60Hz
(Note)
P46
P.21
Acceleration/deceleration
time incrementsʳ
0,1 1 0 P46
