37
Parameter Description
Parameter Description
The table of the special monitor code
tinU tnetnoC noitamrofnI
1etoN .etats trop tupni lanimret lanretxe eht rotinoM 0000H
2etoN .etats trop tuptuo lanimret lanretxe eht rotinoM 1000H
H0002 Monitor the voltage which can be input across terminal 2-5. 0.1V
H0003 Monitor the voltage/current which can be input across terminal 4-5. 0.01A/0.1V
H0004 Monitor the voltage which can be output across terminal AM-5. 0.1V
V1.0 .eulav egatlov rabsub eht rotinoM 5000H
--- etar lamreht cinortcele eht rotinoM 6000H
Note 1. Details of the external terminal input port state.
2. Details of the external terminal output port state.
5.17 Speed Display (P.37)
P.37 “Speed display”
At the output frequency monitoring mode, the screen will display the corresponding mechanical
speed.
Parameter Factory Setting Setting Range Remarks
37 0 r/min 0.1~5000r/min 0: Output frequency
<Setting>
• The set value of P.37 is the mechanical speed of the inverter when its output frequency is 60Hz.
For example: If the transmitting belt speed is 950 m/minute when the inverter output frequency is
60Hz, P.37 shall be set to 950. At the output frequency monitoring mode, the screen
will display the speed of the transmitting belt.
Note: 1. There are time discrepancies (in minutes) between the displayed mechanical speed and the actual one.
2. Please refer to Section 4.1
for detailed operation for the operation panel working mode.
3. When the output mechanical speed is more than 9998, the screen will display 9999.
b0
b15
STFSTRM0M1M2
RES
b0
b15
SO-SEABC
