Introduction of Shihlin Inverter
Introduction of Inverter
3.5 Installation and Wiring
3.5.1 Transport
Transport the inverter by holding the fuselage instead of the cover or any other part of the inverter, or
it may be dropped and damaged.
3.5.2 Stockpile
This product before installing must be placed in the packaging. If it is not in use, change the
frequency to meet the company's warranty scope and future maintenance. Pay attention to the
following matters for storage:
1. Must be placed in a dry and dust-free place.
2. The environment temperature must be stored between -20
to +65 .
3. The relative humidity of the storage location must be ranged from 0% to 95% and without
condensation.
4. Avoid storing the product in an environment with corrosion gas or liquid.
5. The best storage location is on shelves or pallets.
Note: 1. To meet the standard requirements, such as humidity temperature changes also occurred hurriedly
condensation and icy may occur in this place, should be avoided.
2. Do not place the product directly on the ground. Place the product on appropriate shelves. If the storage
environment is not optimal, place the product in desiccant bags.
3. If the custody period is more than 3 months, the ambient temperature shall not be higher than 300C. It is to
avoid electricity deposit in the electrolytic capacitors. The higher the temperature is, the easier the
degradation.
4. When not in use, the inverter installed in the control device or the plate (in construction which especially
the extra humid and dust) should
be removed and stored in an environemtn with the above mentioned
storage conditions.
5. The characteristics of electrolytic capacitors can be degraded if there is no electricity for a long time. Make
sure that the electricity-off state does not last more than one year.
3.5.3 EMC Installation instructions
Inverter is similar to other electrical and electronic equipments. In a power system, an inverter is the
electromagnetic interference source and also the electromagnetic receiver. An inverter will produce
certain electromagnetic interference and noises. In order to guarantee that the inverter to the
electromagnetic environment in certain work, it must be designed to have a certain electromagnetic
interference ability. To achieve a normal operation of the drive system and to satisfy what is
quareenteed by the CE, attain the following criteria for the installation:
1. Field wiring
Power line from power transformer independent power supply generally uses a five-core or a
four-core. It is forbidden for the neutral and the ground to share a common wire.
