Shihlin electric SS2-021 Series User Manual

4
Introduction of Shihlin Inverter
Introduction of Inverter
3. Introduction of Shihlin Inverter
3.1 Electric Specification
3.1.1 220V Series Single-Phase
Model SS2-021- K 0.4K 0.75K 1.5K 2.2K
HP 0.5 1 2 3
Applicable Motor
Capacity
kW 0.4 0.75 1.5 2.2
Rated output capacity kVA (Note) 0.95 1.5 2.5 4.2
Rated output current A (Note) 2.7 4.5 8 11
Over-current capability
150% 60 seconds; 200% 1 second (reverse time
characteristics)
Output
Maximum output voltage 3 Phase 200~240V AC
Rated power voltage Single phase 200~240V 50Hz / 60Hz
Power voltage permissible
fluctuation
Single phase 170~264V 50Hz / 60Hz
Power frequency permissible
fluctuation
±5%
Power
Supply
Power source capacity kVA 1.5 2.5 3.5 6.4
Cooling Method Nature cooling Forced air cooling
Weight (kg) 1.1 1.2 1.6 1.7
3.1.2 220V Series Three-Phase
Model SS2-023- K 0.4 0.75 1.5 2.2 3.7
HP 0.5 1 2 3 5
Applicable Motor
Capacity
kW 0.4 0.75 1.5 2.2 3.7
Rated output capacity kVA (Note) 1.2 2 3.2 4.2 6.7
Rated output current A (Note) 358 11 17.5
Over-current capability
150% 60 seconds; 200% 1 second (reverse time
characteristics)
Output
Maximum output voltage 3 Phase 200~240V AC
Rated power voltage 3 Phase 200~240V 50Hz / 60Hz
Power voltage permissible
fluctuation
3 Phase 170~264V 50Hz / 60Hz
Power frequency permissible
fluctuation
±5%
Power
Supply
Power source capacity kVA 1.5 2.5 4.5 6.4 10
Cooling Method
Nature
cooling
Forced air cooling
Weight (kg) 1.1 1.2 1.2 1.6 1.7
