Appendix 1 Parameter list
Parameter List
Parameter
numberʳ
Nameʳ Setting range
Minimum
setting unit
Default valueʳ
User setting
value
Reference
page
P.40
Multi-function output
terminal pattern
0~10 1 0 P79
P.41
Up-to-frequency
sensitivity
0~100% 0.1% 10% P82
P.42
Output frequency
detection for forward
rotation
0~650Hz 0.01Hz 6Hz P82
P.43
Output frequency
detection for reverse
rotation
0~650Hz, 9999 0.01Hz 9999 P82
P.44 Second acceleration time
0~360.00s/
0~3600.0s,9999
0.01s/0.1s 9999 P46
P.45 Second deceleration time
0~360.00s/
0~3600.0s,9999
0.01s/0.1s 9999 P46
P.46 Second torque boost
0~30%,9999 0.1% 9999 P42
P.47 Second base frequencyʳ
0~650Hz, 9999 0.01Hz 9999 P44
P.48 Data lengthʳ
0, 1 1 0 P58
P.49 Stop bit lengthʳ
0, 1 1 0 P58
P.50 Parity check selectionʳ
0, 1, 2 1 0 P58
P.51 CR and LF selection
1, 2 1 1 P58
P.52
Number of
communication retiesʳ
0~10 1 1 P58
P.53
Communication check
time interval
0~999.8s, 9999 0.1s 9999 P58
P.54
AM terminal function
selection
0~4 1 0 P83
P.55
Frequency monitoring
referenceʳ
0~650Hz 0.01Hz
50Hz/60Hz
(Note)
P83
P.56
Current monitoring
referenceʳ
0~500A 0.01A
Related output
current
P83
P.57 Retry coasting timeʳ
0~30s, 9999 0.1s 9999 P84
P.58 Retry voltage rising timeʳ
0~60s 0.1s 10s P84
P.59 Reserved
