Shihlin electric SS2-021 Series User Manual

138
Appendix 1 Parameter list
Parameter List
Parameter
numberʳ
Nameʳ Setting range
Minimum
setting unit
Default valueʳ
User setting
value
Reference
page
P.197
Frequency corresponds to the
maximum input currentvoltage
across terminal 4-5
0~650Hz 0.01Hz
50Hz/60Hz
˄⊼˅
P112
P.198
Minimum input current/voltage
across terminal 4-5
0~20 0.01 0 P112
P.199
Maximum input current/voltage
across terminal 4-5
0~20 0.01 0 P112
P.223 Analog feedback bias pressure
0~100% 0.1 0% P105
P.224 Analog feedback gain pressure
0~100% 0.1 100% P105
P.225 Panel command
0~100% 0.1 20% P105
P.229
Backlash compensation
function selection
0~1 1 0 P113
P.230
The backlash compensation
acceleration interrupt frequency
0~650Hz 0.01Hz 1Hz P113
P.231
The backlash compensation
acceleration interrupt time
0~360s 0.1s 0.5s P113
P.232
The backlash compensation
deceleration interrupt frequency
0~650Hz 0.01Hz 1Hz P113
P.233
The backlash compensation
deceleration interrupt time
0~360 s 0.1s 0.5s P113
P.234
Triangular wave function
selection
0~2 1 0 P114
P.235 Maximum amplitude
0~25% 0.1% 10% P114
P.236
Amplitude compensation for
deceleration
0~50% 0.1% 10% P114
P.237
Amplitude compensation for
acceleration
0~50% 0.1% 10% P114
P.238 Amplitude acceleration time
0~360s
/0~3600 s
0.01 s/0.1s 10 s P114
P.239 Amplitude deceleration time
0~360s
/0~3600 s
0.01 s/0.1s 10s P114
P.240
Auxiliary frequency function
selection
0~6 1 0 P115
