73
Primary Operation
Primary Operation
noitpircseD spetS
3
• Turn on STF or STR To run the motor.
• At this time, the indicating lamp of
will flicker, indicating that the motor is
running.
Note: 1. Please refer to P.78 and multi-function terminal P.80~P.84, P.86 in Chapter 5 for advanced setting
for starting terminals STF and STR.
2. Please refer to Section 4.1.3
for the operating procedure of the monitoring mode.
3. Choose the programmed operation mode to have STF as the starting signal and STR as the pause
signal. They will no longer act as the run forward or run reversely terminals.
4
• Turn off STF or STR and the motor will decelerate till it stops.
• The indicating lamp of
will stay on until the inverter has stopped putting out
voltages.
4.2.3 Basic operation procedured for the JOG mode ( , Pr79=0 or 1)
noitpircseD spetS
1
• Change the operation mode to the JOG mode and the
indicating lamp of
will be
lit up. The screen will display
before the motor runs.
Note: Please refer to Section 4.1 for selecting and changing the operation modes.
2
• Press
FWD
or
REV
FWD
REV
to run the motor. The indicating lamp of will flicker,
indicating that the motor is running.
• Release or to decelerate the motor till it stops. The indicating lamp
will
stay on until the motor has stopped putting out voltages.
Note: 1. Please refer to Section 4.1.3 for the operation procedures of the monitoring mode.
2. The target frequency at the JOG mode is the value of P.15
, and the acceleration/deceleration
time is the value of P.16. Please refer to P.15 in Chapter 5.
4.2.4 Basic operation procedure for the communication mode ( , P.79=3)
At the communication mode, the user can set up parameters, run/stop, and reset the inverter by
communication. Please refer to P.33
for details.
