93
Primary Operation
Primary Operation
4.2.7 Basic operation procedures for combined mode 3 ( , P.79=6)
The target frequency is determined by communication. When M0, M1, M2 and REX are ‘On’, the
target frequency will be determined by the combination of multi-speed stage levels (Please refer
to P.4~P.6
, P.80~P.84, P.86). When EXJ is ‘On’, the target frequency will be determined by the set
value of P.15
. Acceleration/deceleration time is set by the value of P.16. The starting of the inverter
is determined by external terminals. The functions of P.996
, P.998 and P.999 can be accomplished
by communication.
4.2.8 Basic operation procedured for combined mode 4 (
, P.79=7)
The target frequency of the inverter is determined by the external terminals, external voltage
signals, external current signals, frequency set by pulse (P.82
) or the combination of multi-speed
stage level terminals. The starting of the inverter is determined by communication (including
‘Reset’).
4.2.9 Basic operation procedures for combined mode 5 (
, P.79=8)
The target frequency is determined by the operation panel. When M0, M1, M2 and REX are ‘On’,
the target frequency is determined by the combination of multi-speed stage levels (Please refer to
P.4~P.6
, P.80~P.84, P.86). When EXJ is ‘On’, the target frequency will be determined by the set
value of P.15
. Acceleration/deceleration time is set by the value of P.16. The starting of the inverter
is determined by external terminals.
