47
Parameter Description
Parameter Description
Parameter Factory Setting Setting Range Remarks
5s˄3.7KW and below˅ 0~360s When P.21=0
7
10s˄5.5KW˅ 0~3600s When P.21=1
5s˄3.7KW and below˅ 0~360s When P.21=0
8
10s˄5.5KW˅ 0~3600s When P.21=1
50Hz When P.189=1
20
60Hz
1~650Hz
When P.189=0
0 Minimum setting increment:0.01s
21 0 0, 1
1 Minimum setting increment:0.1s
0~360s When P.21=0
0~3600s When P.21=1
44 9999
9999 Not chosen
0~360s When P.21=0
0~3600s When P.21=1
45 9999
9999 Not chosen
<Setting>
• If P.21=0, the minimum increment of acceleration/deceleration time˄P.7, P.8, P.16, P.44, P.45, and
P.111~P.118
˅is 0.01 seconds.
• If P.21=1, the minimum increment of acceleration/deceleration time˄P.7, P.8, P.16, P.44, P.45, and
P.111~P.118˅is 0.1 seconds.
• If RT is on, the second function is valid. In this case, the running characteristics of the motor are
refer to as the second function.
• If P.44=9999 (the default value), all of the second function is disabled. In this case, even though RT
is on, the acceleration time is still the set value of P.7, and the deceleration time is still the set value
of P.8, the torque boost is still the set value of P.0, and the base frequency is still the set value of P.3
.
• If P.449999 and P.45=9999, the acceleration/deceleration time is the set value of P.44 when RT is
on.
• If P.449999 and P.46=9999, the torque boost is the set value of P. 0
when RT is on.
If P.449999 and P.469999, the torque boost is the set value of P.46 when RT is on.
• If P.449999 and P.47=9999, the base frequency is the set value of P.3 when RT is on.
If P.449999 and P.479999, the base frequency is the set value of P.47 when RT is on.
Note: RT in this paragraph is referred to as the multi-function control terminals. Please refer to P.80~P.84, P.86
for function selection and features and refer to Section 3.5 for wiring.
