Parameter Description
Parameter Description
Modbus
Code
Item
Shihlin
Protocol
Code
Information Content and Functions
Modbus
Address
H03 Inverter State H7A
H0000~H00FF
b8~b15˖reserved
b7˖Alarm occurrence
b6˖Frequency detection
b5˖Parameters to default values end.
b4˖Overload
b3˖Frequency achieved
b2˖Reverse rotation
b1˖Forward rotation
b0˖Operation
H1001
Set frequency H73 H0000~H9C40 H1002
Output
frequency
H6F H0000~H9C40 H1003
Output current H70 H0000~HFFFF H1004
Output voltage H71 H0000~HFFFF H1005
H74 H1007
H03
Monitoring
Alarm
item
H75
H0000~HFFFF:
H74/H1007˖Error code 1 and 2
b15 b8 b7 b0
Error code 2 Error code 1
H75/H1008˖Error code 3 and 4
b15 b8 b7 b0
Error code 4 Error code 3
Error code can reference the table in alarm
history parameters.
H1008
H06/H10 Operation command HFA
H0000~HFFFF
b8~b15: reserved
b7: scram˄MRS˅
b6: 2
nd
Acceleration/Declaration
Selection(RT)
b5: High Speed (RH)
b4: Mid Speed (RM)
b3: :Low Speed (RL)
b2: REV Rotation(STR)
b1: FWD Rotation (STF)
b0: reserved
H1001
H06/H10 Inverter reset HFD
H9696˖The function of P.997
Communicate with the computer: the
inverter can not send data back to the
computer because it has been reset.
H1101
