SECTION 1 OUTLINE AND DESCRIPTIONS
6
263-13236
1
1.2.2 Standard Accessories
Series of TMP-3203
TMP-3403LMC
(Note) One of followings.
Description Q'ty Notes Parts number
1
Gasket for inlet flange
(Note)
1
O-ring gasket for VG350
O-ring gasket for VG300
O-ring gasket for ISO320B Special
O-ring gasket for VG250
036-13516
036-13515
036-15554-55
036-13514
2
Bolt set for inlet flange
(Note)
1
VG350：Hex Head, M12 × 40, 12PC
(A2-70)
VG300：Hex Head, M12 × 35, 12PC
(12.9)
ISO320B Special： Hex Head,
M12 × 40, 12PC (12.9)
VG250：Stud Bolt, M12 × 47, 12PC
(12.9)
─
3 Centering with O-ring 1
KF40
035-06004-14
4Clamp 1
KF40
035-06004-03
5 Instruction manual 1 English
263-13236
Description Q'ty Notes Parts number
1
Gasket for inlet flange
(Note)
1
O-ring gasket for VG350
O-ring gasket for VG300
O-ring gasket for ISO320B Special
O-ring gasket for VG250
036-13516
036-13515
036-15554-55
036-13514
2
Bolt set for inlet flange
(Note)
1
VG350：Hex Head, M12 × 40, 12PC
(12.9)
VG300：Hex Head, M12 × 35, 12PC
(12.9)
ISO320B Special： Hex Head,
M12 × 40, 12PC (12.9)
VG250：Stud Bolt, M12 × 47, 12PC
(12.9)
─
3 Centering with O-ring 1
KF40
035-06004-14
4Clamp 1
KF40
035-06004-03
5 Instruction manual 1 English
263-13236
