5.2 Connection of the Pump to the Power Supply Unit
CAUTION
Insert straight the control cable connector after checking its key direction.
Inserting it in oblique direction would cause damage of the connector pins. After the insertion,
turn the cable connector clockwise until the rotation lock clicks.
CAUTION
Don't disconnect each cable while the pump is running. Particularly before disconnecting the
control cable, Check complete shutdown of the pump by ROTATION lamp goes out and,
thereafter, turn off the POWER switch.
For information regarding cable connections please refer to the Power Supply Unit Instruction
Manual.
