SECTION 5 INSTALLATION
20
263-13236
5
CAUTION
The center of gravity of the pump is indicated in Fig. 5-8. Be sure that the pump does not move
or fall down during installation or storage.
CAUTION
The casters provided with the pump are only auxiliary equipment for installation and storage.
Use a trolley etc. for long-distance transportation.
Fix the pump in the manner shown in Fig. 5-2
Fig. 5-2 Lifting Method
Vacuum
chamber
Vacuum
chamber
PUMP
PUMP
