Shiv Expert - Cleaning the Reservoir

 Fig.3: Thread the screw supplied with the Fuelselage into the threaded rivet. The ferromagnetic screw allows the
mouth port magnet to function.
 Fig.3: Place the clip at the front of the mouth port under the lip of the top tube port, then lower the magnetic tip
of the mouth port down until the magnet comes in contact with the screw.
4 5
 Fig.4: Place the magnet loop around the aero extension, on the desired side.
 Fig.4: Once the rider position and magnet loop position are determined, if the hose is too long, remove the
silicone straw and carefully cut the hose down to the desired length, so that the magnet in the silicone straw lines
up with the magnet loop.
 Fig.5: Fill the reservoir with drinking fluid.
Do not fill with alcohol, milk products or hot beverages.
A video instruction guide is available at http://servicevideos.specialized.com.
CLEANING THE RESERVOIR
 To prevent mold growth, always rinse out the reservoir and hang to dry in a well ventilated area after every use.
Store in a clean, dry environment.
 Periodically clean the reservoir by following these steps:
• Fill the reservoir, tube and bite valve with a solution of warm water and a hydration pack cleaning tablet, a couple of
tablespoons of baking soda or a mild dish detergent. Scrub the inside of the reservoir and tube with brushes for best
cleaning results, then close the reservoir. Do NOT use boiling water! This can damage the reservoir.
• Shake the solution in the reservoir and allow some solution to exit the tube. Allow the solution to sit in the reservoir and tube
for 15-30 minutes.
• Rinse with fresh water, then allow the reservoir and tube to airdry completely.
