23
Ordercode: 40073
Phantom 130 Spot
Channel 15 – Channel Functions
0-7
Not functional
8-15
Blackout during Pan/Tilt movement
16-23
Blackout during color wheel movement
24-31
Blackout during gobo wheel movement
32-39
Blackout during Pan-Tilt/color wheel movement
40-47
Blackout during Pan-Tilt/gobo wheel movement
48-55
Blackout during Pan-Tilt/color wheel movement/gobo wheel movement
56-95
Not functional
96-103
Reset Pan
104-111
Reset Tilt
112-119
Color wheel reset
120-127
Gobo wheel reset
128-135
Not functional
136-143
Reset prism
144-151
Focus/zoom reset
152-159
Reset all
160-255
Not functional
Channel 16 – Built-in Programs + Sound-controlled Programs
0-7
No Function
8-23
Built-in Program 1
24-39
Built-in Program 2
40-55
Built-in Program 3
56-71
Built-in Program 4
72-87
Built-in Program 5
88-103
Built-in Program 6
104-119
Built-in Program 7
120-135
Built-in Program 8
136-151
Sound-controlled Program 1
152-167
Sound-controlled Program 2
168-183
Sound-controlled Program 3
184-199
Sound-controlled Program 4
200-215
Sound-controlled Program 5
216-231
Sound-controlled Program 6
232-247
Sound-controlled Program 7
248-255
Sound-controlled Program 8
