Shure Incorporated
97/103
NCS4 1.7 kg (3.7 lbs)
NCS2 0.8 kg (1.8 lbs)
Audio Network Interface (ANI)
Audio Network Interface (ANI)
Audio Frequency Response
20 Hz to 20 kHz (+1, −1.5 dB)
Dynamic Range
20 Hz to 20 kHz, A-weighted, typical
Analog-to-Dante 113 dB
Dante-to-Analog 110 dB
Output Noise
20 Hz to 20 kHz, A-Weighted, typical
Line Aux Mic
−84.5 dBV −95.2 dBV −106.5 dBV
THD+N
20 Hz to 20 kHz +4dBu analog input, −10 dBFS digital input
<0.05%
Polarity
Non-inverting, any input to any output
Dimensions
44 mm x 483 mm x 366 mm (1.7 in. x 19.0 in. x 14.4 in.), H x W x D
Weight
MXWANI4 3.1 kg (6.9 lbs)
MXWANI8 3.2 kg (7.1 lbs)
Housing
Steel; Extruded aluminum
Power Requirements
100 to 240 V AC, 50-60 Hz, 1 A
Operating Temperature Range
−18°C (0°F) to 63°C (145°F)
Storage Temperature Range
−29°C (20°F) to 74°C (165°F)
