Shure Incorporated
20/56
•
•
•
•
•
•
•
•
•
•
•
1.
2.
3.
1.
Note: Menu is not selectable when Shure rechargeable batteries are installed.
Auto Lock Turn the transmitter auto lock on or off
Lock Type
Determine auto lock behavior:
Menu Only: Locks the menu to prevent transmitter settings from being changed
Menu & Power: Locks the menu and disables the power switch
Phantom Power*
Select a phantom power setting:
Off (default setting)
+12 V
+48 V
*SLXD3 only
Pad/Boost*
Select input pad or boost to avoid overloading the audio input, or increase low-output audio
sources:
Off (default setting)
Pad: −12 dB
Boost: +12 dB
*SLXD3 only
About Displays the firmware, hardware, and band information
Locking and Unlocking the Receiver Controls
The following control lock options can be accessed under 5. Advanced Settings > 5.1 Device Lock:
Unlock: receiver controls are unlocked
Lock Menu: prevents access to menu items (receiver can still be powered off)
Lock Menu & Power: disables the power switch as well as menu controls
Select the desired option and press the control knob to confirm.
Transmitter Auto Lock
The transmitter controls can be locked or unlocked by selecting On (locked) or Off (unlocked) from the transmitter Auto Lock
menu. When auto lock is enabled, the transmitter controls lock when you return to the home screen.
Note: The enter button can still be used to change the home screen display on a locked transmitter.
To activate auto lock:
Press the menu button to navigate to the Auto Lock settings.
Use the enter button to edit and the menu button to select On.
Press enter to save. The lock icon appears on the display to confirm that the control locks are enabled.
To unlock the transmitter and deactivate auto lock:
Press enter then menu to unlock the transmitter controls.
