FREQUENCY TABLES
H5: 518.000 - 542.000 MHz
J3: 572.000 - 596.000 MHZ
Preprogrammed frequencies in total: > 120
Group 1 Group 2 Group 3 Group 4 Group 5 Group 6
1 518.400 519.250 518.200 519.775 519.100 518.425
2 521.500 520.500 519.675 522.500 521.225 520.400
3 523.575 522.225 520.800 524.200 522.550 523.425
4 525.050 524.725 522.450 525.600 524.575 525.475
5 527.425 526.350 523.750 526.700 526.900 527.775
6 529.200 527.550 526.200 528.250 530.500 531.675
7 532.450 530.800 528.325 529.500 531.750 533.800
8 533.650 532.575 532.225 533.100 533.300 536.250
9 535.275 534.950 534.525 535.425 534.400 537.550
10 537.775 536.425 536.575 537.450 535.800 539.200
11 539.500 538.500 539.600 538.775 537.500 540.325
12 540.750 541.600 541.575 540.900 540.225 541.800
Explanation of group
content
Full Range even
distribution for each
TV-CH (option 1)
Full Range even
distribution for each
TV-CH (option 2)
Full Range max. # of
frequencies for CH-
22 (option 1)
Full Range max. # of
frequencies for CH-
23 (option 1)
Full Range max. # of
frequencies for CH-
24 (option 1)
Full Range max. # of
frequencies for CH-
25 (option 1)
Preprogrammed frequencies in total: > 120
Group 1 Group 2 Group 3 Group 4 Group 5 Group 6
1 572.400 573.250 572.200 573.775 573.100 572.425
2 575.500 574.500 573.675 576.500 575.225 574.400
3 577.575 576.225 574.800 578.200 576.550 577.425
4 579.050 578.725 576.450 579.600 578.575 579.475
5 581.425 580.350 577.750 580.700 580.900 581.775
6 583.200 581.550 580.200 582.250 584.500 585.675
7 586.450 584.800 582.325 583.500 585.750 587.800
8 587.650 586.575 586.225 587.100 587.300 590.250
9 589.275 588.950 588.525 589.425 588.400 591.550
10 591.775 590.425 590.575 591.450 589.800 593.200
11 593.500 592.500 593.600 592.775 591.500 594.325
12 594.750 595.600 595.575 594.900 594.225 595.800
Explanation of group
content
Full Range even
distrobution for each
TV-CH (option 1)
Full Range even
distrobution for each
TV-CH (option 2)
Full Range max. # of
frequencies for CH-
31 (option 1)
Full Range max. # of
frequencies for CH-
32 (option 1)
Full Range max. # of
frequencies for CH-
33 (option 1)
Full Range max. # of
frequencies for CH-
34 (option 1)
