AGENCY APPROVALS
Note: Consult Global Compliance for latest applicable standards
PRODUCT PERFORMANCE CHARACTERISTICS
JB MODEL (CHANGES FROM R5 MODEL)
FCC (H5, J3, L4) - Part 74
IC (H5, J3, L4) - RSS-123
ETS (H5, J3, L4, P4, Q4, R5, S6,) - EN 300 422 and EN 301 489
TELEC (JB) - RCR STD-22
SPECIFICATION Value
Operating Frequency (H5) 518.100 to 541.900 MHz
Operating Frequency (J3) 572.100 to 595.900 MHz
Operating Frequency (L4) 638.100 to 661.900 MHz
Operating Frequency (P4) 702.100 to 725.900 MHz
Operating Frequency (Q4) 740.100 to 751.900 MHz
Operating Frequency (R5) 800.100 to 819.900 MHz
Operating Frequency (S6) 838.100 to 864.900 MHz
Operating Frequency (JB) 806.125 to 809.750 MHz
Number of User Selectable Channels See frequency table
Type of Emission 120KF3E
Oscillator PLL-controlled synthesizer
RF Conducted Power Output Band Dependent (See Table 1)
Tonekey Signal 32.768kHz
Maximum FM Deviation 38 kHz
Dynamic Range > 100 dB
Total Harmonic Distortion < 0.7% (38 kHz deviation, 1 kHz)
Audio Adjustment Range -10, 0, or +15 dB; user selectable
Operating Voltage 3V (2 x AA; alkaline or rechargeable)
Power Consumption 130mA ± 15mA @ 3V
Battery Life > 8 hrs (alkaline batteries)
Operating Frequency 806 to 810 MHz
Number of User Selectable Channels 16 (125 kHz Spacing)
Frequency Stability ± 10 ppm
Reference FM Deviation1 kHz audio level 5 kHz -23.47 dBu (52 mV) at TPA0
Output Power See Table 1
