SLX2 REPLACEMENT PARTS (TOP)
SLX2 REPLACEMENT PARTS (BOTTOM)
MP6 Bezel 65A8475B
MP7 Pushbutton Switch Actuator (Power/Mute/Select) 66A8070
MP8 Battery Cup 65BA8451
MP9 Frequency Nameplate 39__8466
Provide
Frequency Code
In The Space
MP10 PCB Screw 30J1245B
MP11 Battery Nest Screws 30D443E
MP12 RF Shield Cover 53A8590A
MP13 LCD Holder/Backlight 65A8452
MP14 LCD Bezel 53A8573B
MP15 LCD 95A8991
MP16 LCD Zebra Connector 80A8257
MP17 Compression Pad (For Positive Battery Contact) 38D189
Reference
Designation
Description Shure
Part Number
C100 Capacitor, Tantalum, SMD1206, 15uF, 10V, 10% 151AC156KA
C162 Capacitor, Tantalum, SMD1411, 10uF, 16V, 10% 151AD106KB
C531 Capacitor, Tantalum, SMD1206, 0.1uF, 35V, 10% 151AG104KA
C432, 548, 549 Capacitor, Tantalum, SMD1411, 100uF, 6V, 10% 151AB107KB
DS375 Chippled Green LED 184A77
DS420 Bicolor (Red/Green) LED 184A39
E408, 500 Bead, Ferrite, SMD 805, 600 OHM 162A12
IC1 L.C.D. Backlight Holder 65A8452
IC100 28 Pin QSOP Compander (THAT4320) 188A568
IC370 1K Microwire EEPROM (93AA46AT-I/OT) 188A577
IC350 Segment-Type, LED Driver 188A506
IC430 3.3V CMOS LDO Regulator (SP6213EC5) 188A590
Q185 Low Noise Transistor (MMBT5089L) 183A38
Q410 Transistor, Power, Mosfet (NSD355AN) 183A74
SW324, 325 Switch, Pushbutton, Momentary, SPST 155A21
Y331 Crystal, Quartz, SMD, 32.768 kHz 40A8010
Reference
Designation
Description Shure
Part Number
CON100 3 Pin Socket Strip (Female) For headboard 170C15
CON301 3 Pin Socket Strip (Female) For IF cable 95A9054
CON600 Positive Battery Contact 53A8591
CON601 Negative Battery Contact 95A9064
CON640 Connector, COAX w/Switch (ONLY JB models) 170A36
CV500 Trim Cap., SMD, 0.65 - 2.5pF 152A04
CV501 Trim Cap., SMD, 3.0 - 15pF 152E05
D162, 190 Switching Dual Diode, SMD (MMBD2836L) 184A07
D400, 480 Common Anode Schottky Diode (BAT 54A) 184B69
D500 Variable Capacitance Diode 184A72
D600 Dual Schottky Diode (BAT 54S) 184A69
E100 Bead, Ferrite, SMD 805, 600 OHM 162A12
IC150 Quad Op. Amp., SO-14 (MC33179) 188A49
IC400 Sync Boost Converter (LTC3400ES6) 188A479
IC501 Low Power Dual Synthesizer (LMX2335LTM) 188B388
