Shure SLX2 - Frequency Dependent Parts

33
25A1090 (Rev.3)
MICROCONTROLLER (IC300) SELECTION
FREQUENCY DEPENDENT PARTS**
L404 Inductor, SMD 2518, 4.7nH 162A64
L501, 503 Inductor, SMD 603, 100nH 162A25
L600, 601 Inductor, SMD 603, 150nH 162AE56
L611 Inductor, SMD 603, 10nH 162N25
Q205 Transistor, TMOS, SOT-23 (2N7002L) 183A30
Q475 Transistor, Power, Mosfet (NSD355AN) 183A74
Q501, 502 Transistor, High Frequency (2SC5006) 183A66
Q600 Transistor, SOT-23 (AT-41533) 183A49
Q601 Transistor, Bipolar, Silicon (AT-41486) 183A44
Q630 Transistor, PNP, SOT-23 (MMBT2907L) 183A27
Q375, 480, 631 Transistor, Low Noise, SOT-23 (MMBT5089L) 183A38
SW324, 325 Switch, Pushbutton, Momentary, SPST 155A21
SW100 Switch, Slide, 2-Position 155A32
TR160, 200 Trim-pot., Line, 100KΩ 146E10
TR640 Trim-pot., Line, 470Ω 146A10
Y500 Crystal, Quartz, SMD, 16MHz 140A26
Country
Code
Shure Part Number
H5 188A585A
J3 188B585A
L4 188C585A
P4 188D598A
Q4 188E585B
R5 188F585A
S6 188G585A
JB 188H585B
Frequency
Code
H5 J3 L4 P4 Q4 R5 S6 JB
C506 150pF 68pF 68pF 68pF 68pF 68pF 68pF 68pF
C522 6.8pF 5.6pF 4.7pF 3.9pF 3.9pF 3.3pF 3.3pF 3.3pF
C523 3.3pF 3.9pF 2.7pF 2.2pF 3.9pF 2.2pF 2.2pF 2.2pF
C525 3.9pF 3.9pF 2.2pF 2.2pF 1.8pF 1.8pF 1.8pF 1.8pF
C528 3.3pF 1.5pF 2.2pF 1.0pF 2.7pF 1.5pF 1.0pF 1.5pF
C534 3.9pF 3.9pF 2.7pF 2.7pF 2.2pF 2.2pF 2.2pF 2.2pF
C543 12pF 10pF 4.7pF 4.7pF 6.8pF 6.8pF 6.8pF 6.8pF
C551 8.2pF 5.6pF 4.7pF 4.7pF 5.6pF 5.6pF 5.6pF 5.6pF
C603 120pF 68pF 68pF 68pF 68pF 68pF 68pF 68pF
C611 3.9pF 2.7pF 2.7pF 2.2pF 3.9pF 3.9pF 3.3pF 3.9pF
C612 10pF 6.8pF 6.8pF 6.8pF 10pF 10pF 5.6pF 10pF
C615 2.7pF 2.2pF 2.2pF 2.2pF 2.2pF 2.2pF 3.3pF 2.2pF
C616 10pF 12pF 12pF 12pF 12pF 12pF 10pF 12pF
C617 6.8pF 8.2pF 8.2pF 8.2pF 8.2pF 8.2pF 8.2pF 8.2pF
C618 12pF 10pF 5.6pF 3.9pF 6.8pF 6.8pF 4.7pF 6.8pF
C619 120pF 68pF 68pF 68pF 68pF 68pF 68pF 68pF
C651 8.2pF 6.8pF 4.7pF 2.2pF 5.6pF 5.6pF 5.6pF 5.6pF
C97 DNP DNP DNP DNP DNP DNP DNP DNP
E301 600Ω DNP DNP DNP DNP DNP DNP DNP
E302 600Ω DNP DNP DNP DNP DNP DNP DNP
E303 600Ω DNP DNP DNP DNP DNP DNP DNP
