Shure SLX2 - Page 34

34
25A1090 (Rev.3)
E603 600Ω 600Ω 600Ω 600Ω DNP DNP DNP DNP
L301 DNP 220nH 220nH 220nH 180nH 180nH 180nH 180nH
L302 DNP 220nH 220nH 220nH 180nH 180nH 180nH 180nH
L303 DNP 220nH 220nH 220nH 180nH 180nH 180nH 180nH
L400 470nH 470nH 470nH 470nH 220nH 220nH 220nH 220nH
L401 470nH 470nH 470nH 470nH 220nH 220nH 220nH 220nH
L502 15nH 15nH 15nH 12nH 6.8nH 6.8nH 6.8nH 6.8nH
L505 5.4nH 5.4nH 3.85nH 3.85nH 2.55nH 2.55nH 2.55nH 2.55nH
L602 22nH 22nH 18nH 15nH 8.2nH 8.2nH 8.2nH 8.2nH
L603 DNP DNP DNP DNP 180nH 180nH 180nH 180nH
L604 18nH 18nH 12nH 12nH 8.2nH 8.2nH 10nH 8.2nH
L605 15nH 12nH 8.2nH 8.2nH 6.8nH 6.8nH 6.8nH 6.8nH
L606 15nH 12nH 8.2nH 8.2nH 6.8nH 6.8nH 6.8nH 6.8nH
L607 15nH 8.2nH 12nH DNP 8.2nH 8.2nH 12nH 8.2nH
L640 DNP DNP DNP DNP DNP DNP DNP 12nH
L641 6.8nH 8.2nH 10nH 1.2nH 12nH 12nH 12nH DNP
R1 1K DNP DNP DNP DNP DNP DNP DNP
R2 DNP 1K DNP DNP DNP DNP DNP DNP
R201 121K 150K 121K 121K 121K 121K 150K 150K
R3 DNP DNP 1K DNP DNP DNP DNP DNP
R320 1K 3.01K 4.99K 18.2K 30.1K 7.5K 12.1K 7.5K
R4 DNP DNP DNP 1K DNP DNP DNP DNP
R5 DNP DNP DNP DNP 1K DNP DNP DNP
R6 DNP DNP DNP DNP DNP 1K DNP DNP
R606 22.1Ω 22.1Ω 22.1Ω 22.1Ω 22.1Ω 22.1Ω 22.1Ω 49.9Ω
R607 DNP DNP DNP 0Ω DNP DNP DNP DNP
R612 499Ω 499Ω 499Ω 499Ω 221Ω DNP DNP 221Ω
R613 10Ω 10Ω 10Ω 10Ω
22.1Ω 0Ω 10Ω 22.1Ω
R614 499Ω 499Ω 499Ω 499Ω 221Ω DNP DNP 221Ω
R640 DNP DNP DNP DNP DNP DNP DNP 33.2Ω
R650 499Ω 499Ω 499Ω 499Ω 221Ω 499Ω 221Ω 221Ω
R651 10Ω 10Ω 10Ω 10Ω 22.1Ω 18.2Ω 22.1Ω 22.1Ω
R652 499Ω 499Ω 499Ω 499Ω 221Ω 499Ω 221Ω 221Ω
R653 22.1Ω 22.1Ω 22.1Ω 22.1Ω 22.1Ω 10Ω 10Ω 22.1Ω
R7 DNP DNP DNP DNP DNP DNP 1K DNP
R8 DNP DNP DNP DNP DNP DNP DNP 1K
