Inputs and Outputs
UR1 Transmitter Audio Input
Connector: 4-Pin male mini connector (TA4M)
Input Configuration: Unbalanced, active
Maximum Input Level:
(1 kHz, 1% THD)
+10 dBu (sensitivity 0 dB)
+20 dBu (sensitivity –10 dB)
TA4M Connector Pin
Assignments:
Pin 1: Ground
Pin 2: +5 Vdc bias
Pin 3: Audio, 200 kW
Pin 4: Tied through active load (on main board)
to Ground.
(On instrument adapter cable, Pin 4 floats)
UR2 Transmitter Audio Input
Input Configuration: Unbalanced, active
Actual Impedance: >1 MW
Maximum Input Level:
1 kHz, 1% THD
+4.8 dBu
UR1, UR1M Transmitter RF Output
Connector: SMA
Actual Impedance: 50 W
Pin Assignments: Shell = Ground
Center = Signal
Replacement Parts and Accessories
Furnished Accessories
Microphone Stand Adapter (UR2)
WA371
Threaded locking Adapter (with TA4F), UR1
WA340
Zipper Bag (UR1)
26A13
Zipper Bag (UR2)
26A14
Antenna (UR1, UR1M) 470-530 MHz
UA700
Antenna (UR1, UR1M) 518-578 MHz
UA710
Antenna (UR1, UR1M) 578-698 MHz
UA720
Antenna (UR1, UR1M) 740-865 MHz
UA730
Antenna (UR1, UR1M) 944-952 MHz
UA740
Transmitter Carrying Case
95C9053
Optional Accessories
SM58 Head with Grille
RPW112
SM86 Head with Grille
RPW114
BETA 58 Head with Grille
RPW118
BETA 87A Head with Grille
RPW120
BETA 87C Head with Grille
RPW122
SM87A Head with Grille
RPW116
KSM9/SL Head with Grille
RPW180
KSM9HS Head with Grille (Champagne, Condenser)
RPW182
KSM9/BK Head with Grille
RPW184
KSM9HS Head with Grille (Black, Condenser)
RPW186
Matte Silver Grille (SM58)
RK143G
Matte Silver Grille (SM86)
RPM266
Matte Silver Grille (BETA 58)
RK265G
Black Grille (SM87)
RK214G
Matte Silver Grille (BETA 87A)
RK312
Matte Silver Grille (BETA 87C)
RK312
Black Grille (BETA 58)
RK323G
Black Grille (BETA 87A/BETA 87C)
RK324G
Champagne Grille (KSM9/SL)
RPM260
Black Grille (KSM9/BK)
RPM264
Popper Stopper‘ Windscreen
A85WS
Belt Clip (UR1)
44A8031
Bodypack Pouch (Black), UR1
WA580B
Bodypack Pouch (White), UR1
WA580W
Bodypack Pouch (Black), UR1M
WA581B
Bodypack Pouch (White), UR1M
WA581W
3-Pin mini Lemo conversion kit, UR1M
WA335
Mute Switch for Bodypack
WA661
Mute Switch for 2 Bodypacks
WA662
Architects' and Engineers' Specifications
The wireless system shall operate in the UHF band between 470-865 MHz and 944-952 MHz, with the specific range being dependent on the user's locale. The system
shall include the option of changing the operating frequency in order to avoid RF interference, enabling up to 160 systems to operate simultaneously in the same location.
Preconfigured group, channel and frequency setups shall be available to ensure that multiple systems in use do not interfere with one another.
All transmitters shall be powered by 2 AA batteries and shall have a power on/off switch. The bodypack will have an LED indicating that power is on. Available transmitters
shall include: a body pack for use with electric guitars, basses, and other electric instruments, and a handheld microphone for vocals. The transmitters shall have a DC/DC
converter to ensure consistent performance, even if battery voltages change.
The receiver shall have a user-programmable, menu-driven LCD showing group, channel, frequency, name, squelch level, and locked/unlocked status. The system shall use
technology such as MARCAD‚ signal combining circuitry to improve reception, minimize signal dropouts, and achieve the best possible signal-to-noise ratio. An equalizer,
tone key squelch, and noise squelch circuitry shall be built into the system to provide optimal sound quality and minimize unwanted noise. The receiver shall include dual RF
meters (one for each antenna), an audio level meter, and a Networking Interface connector for computer control and monitoring. The receiver shall have a volume control and
an adjustable noise squelch control.
The system shall be the Shure UHF-R Wireless.
