Storage Temperature Range
-29°C (-20°F) to 74°C (165°F)
Note: Battery characteristics may limit this range.
ULXD4D & ULXD4Q
ULXD4D
Weight
3.36 kg (7.4 lbs), without antennas
Power Requirement
100 to 240 V AC, 50-60 Hz, 0.26 A max.
ULXD4Q
Weight
3.45 kg (7.6 lbs), without antennas
Power Requirement
100 to 240 V AC, 50-60 Hz, 0.32 A max.
ULXD4D & ULXD4Q
Dimensions
44 x 482 x 274 mm H x W x D
Housing
steel; Extruded Aluminum
Audio Output
Gain Adjustment Range
−18 to +42 dB in 1 dB steps (plus Mute setting)
Configuration
XLR balanced (1=ground, 2=audio +, 3=audio −)
Impedance
100 Ω
Full Scale Output
LINE setting +18 dBV
MIC setting −12 dBV
Mic/Line Switch
30 dB pad
