EMC compatibility according to the Council Directive: 2004/108/EG;
applied harmonized standards: EN 61326-1:2006
Low-voltage directive according to the Council Directive 2006/95/EG
Testing basis EN 61 010, Part 1
Country of origin: Germany, Made in Germany
The following solvents/titration reagents are allowed to be used:
− All common titration solutions.
− As reagent water and all non-aggressive non-organic and organic fluids are allowed. If using combustible
fluids fire please adhere to the Guidelines for Explosion Protection and Prevention of the chemical industry.
− For fluids with higher viscosity (≥ 5 mm
2
/s), lower boiling point or affinity to outgas, the filling and dosage
speed can be adjusted.
− Fluids with viscosity over 20mm
2
/s cannot be dosed.
Measurement input: Karl-Fischer (Dead-stop) connector for double platinum electrode
Polarisation voltage variably adjustable from 40 … 220 mV.
Connector: 2 x 4 mm - sockets.
