SICE S 60 - MAIN OPERATING ELEMENTS (FIG.11); Identification of Controls

User Manual S60 73
UK
Fig.10showsthesafetydistancesandthepositionsusedbytheoperatorduringthe
various work phases:
A Positioning the wheel on the turntable
B Inner bead breaking
C Outer bead breaking, demounting and mounting.
MAIN OPERATING ELEMENTS (FIG.11)
A Main switch
B Control lever
C Pressure gauge
D Control unit group
E Turntable
F Bead breaker disc
G Tool
H Ratchets
I Tool arm
L Toolunit
A
CB
10
