Dimensional drawings
GB
6 Dimensional drawings
 Mounting kit 6  Protective field height
 M8 hex screw, DIN 933, with washer DIN 9021
(not in the delivery)
 Sliding nut groove for side mounting
S1 L1 S1 L1
150 246 750 816
300 364 900 967
450 515 1050 1117
600 666 1200 1266
Fig.
3
:
Dimensional drawings
and dimensions C2000 Eco,
sender (receiver mirror
image), side bracket,
protective field heights
S1 = 150 … 1200 mm
Ca.
Ca.
