SICK C4000 Fusion Ex User Manual

WARNING
Ris
k of ineffectiveness of the protective device
Please observe the following information to ensure that you are using the C4000
Fusion Ex safety light curtain safely and correctly.
b
National and international regulations and guidelines must be observed when
mounting, using, and commissioning electrical devices as well as when carrying
out regular technical inspections in explosion-hazardous areas. Article 500 of the
National Electrical Code and ATEX Directive 2014/34/EU shall apply in particular.
Manufacturers and operators of machines using safety light curtains are responsi‐
ble for ensuring that all applicable safety regulations and guidelines are complied
with.
b
These operating instructions must be made available to the operator of the
machine on which the safety light curtain is used. Qualified safety personnel must
instruct the operator in how to use the device. The operator must also be directed
to read and follow the operating instructions.
DANGER
Ris
k of ignition
Failure to observe this instruction can result in a risk of ignition from potential sparking.
b
Ensure that only accessories that are approved for explosion-hazardous areas are
used.
NOTE
SIC
K provides more information about the following explosion-proof connections:
•
Joint between glass and cover
•
Joint between cover and explosion-proof enclosure
SAFETY INFORMATION 2
8022867/2019-03-04 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Fusion Ex
7
Subject to change without notice

SICK C4000 Fusion Ex Specifications

General

Supply voltage	24 V DC
Enclosure rating	IP65, IP67
Operating Voltage	24 V DC
Protection Rating	IP65, IP67
Resolution	30 mm
Protective field height	300 mm ... 1, 800 mm (depending on the variant)
Synchronization	Optical, cable
Ambient operating temperature	-30 °C ... +55 °C (depending on the variant)
Operating Temperature	-30 °C ... +55 °C (depending on the variant)
Outputs	2 safety outputs (OSSDs), 1 diagnostic output
