SICK CLV6 Series User Manual

CLV6 SERIES | SICK8016144/2013-09-19
Subject to change without notice
25
BAR CODE SCANNERS CLV62x
Detailed technical data
Features
CLV620 Mid Range CLV621 Long Range CLV622 Short Range
Light source
Visible red light (655 nm)
MTBF
40,000 h
Laser class
2 (EN 60825-1 (A2:2001-03), IEC 60825-1 : 2007-03, Ed. 2.0)
Field of view
≤ 50°
Scanning frequency
400 Hz ... 1,200 Hz
Code resolution
0.2 mm ... 1 mm 0.35 mm ... 1 mm 0.15 mm ... 0.5 mm
Reading distance (at code resolution)
60 mm ... 365 mm (1 mm) 60 mm ... 730 mm (1 mm) 55 mm ... 200 mm (0.5 mm)
Raster height, number of lines, at distance
15 mm, 8, 200 mm
15 mm, 8, 185 mm
(depending on type)
Performance
Bar code types
All current code types, Code 39, Code 128, Code 93, Codabar, GS1-128 / EAN 128,
UPC / GTIN / EAN, Interleaved 2 of 5, Pharmacode, GS1 DataBar, Telepen, MSI/Plessey
Print ratio
2:1 ... 3:1
No. of codes per scan
1 ... 20 (Standard decoder)
1 ... 6 (SMART620)
No. of codes per reading interval
1 ... 50 (auto-discriminating)
No. of characters per reading interval
1,500
500 (for multiplexer function in CAN operation)
No. of multiple readings
1 ... 99
Interfaces
Serial (RS-232, RS-422/485)
l, AUX (only RS-232)
Function Host, AUX
Data transmission rate 2,400 Baud ... 115 kBaud, AUX: 57.6 kBaud
Ethernet
– / l (depending on type)
Function Host, AUX
Data transmission rate 10/100 Mbit
Protocol TCP/IP, EtherNet/IP, PROFINET, PROFINET Dual Port (optional via external connection module
CDF600-2), EtherCAT (optional via external connection module CDF600)
(depending on type)
CAN bus
l
Function SICK CAN sensor network (Master/Slave, Multiplexer/Server)
Data transmission rate 20 kbit/s ... 1 Mbit/s
Protocol CANopen, CSN (SICK CAN Sensor Network)
PROFIBUS DP
l, optional via external connection module (CDF600-2)
DeviceNet
l, optional via external connection module (CDM + CMF)
Switching inputs
Cable 4 (“Sensor 1”, “Sensor 2”, 2 inputs via optional CMC600 in CDB620/CDM420)
Ethernet 3 (“Sensor 1”, 2 inputs via optional CMC600 in CDB620/CDM420)
Switching outputs
Cable 4 (“Result 1”, “Result 2”, 2 outputs via optional CMC600 in CDB620/CDM420)
Ethernet 2 (via CMC600 in CDB620/CDM420)
