CLV6 SERIES | SICK 8016144/2013-09-19
Subject to change without notice
26
CLV62x BAR CODE SCANNERS
Reading pulse
Switching inputs, non-powered, serial interface, auto pulse, CAN
Optical indicators
6 LEDs (Ready, Result, laser, Data, CAN, LNK TX)
Acoustic indicators
Beeper/buzzer (can be switched off, can be allocated as a result indication function)
Mechanics/electronics
CLV620 Mid Range CLV621 Long Range CLV622 Short Range
Electrical connection
Cable 1 15-pin D-Sub HD male connector (0.9 m)
Ethernet 2 M12 cylindrical connectors (12-pin male connector, 4-pin female connector) on swivel con-
nector
Operating voltage
10 V DC ... 30 V DC
Power consumption
4.5 W
Housing
Die-cast aluminum
Housing color
Light blue (RAL 5012)
Enclosure rating
IP 65 (DIN 40 050)
Protection class
III (VDE 0106/IEC 1010-1)
Weight
Cable 225 g ... 250 g, with connecting cable (depending on type)
Ethernet 205 g ... 230 g, without connecting cable (depending on type)
Dimensions
Front 61 mm x 66 mm x 38 mm
1)
Side 80 mm x 66 mm x 38 mm
1)
1)
Swivel connector is 15 mm longer with Ethernet model.
Ambient data
Electromagnetic compatibility (EMC)
EN 61000-6-3 (2001-10) / EN 61000-6-2:2005
Vibration resistance
EN 60068-2-6 (1995)
Shock resistance
EN 60068-2-27 (1993)
Ambient operating temperature
0 °C ... +40 °C
Storage temperature
–20 °C ... +70 °C
Permissible relative humidity
90 %, non-condensing
Ambient light safety
2,000 lx, on bar code
Bar code print contrast (PCS)
≥ 60 %
Ordering information
• Focus: Fixed focus
• Front screen: Glass
Version Connection type Reading eld Scanner design Model name Part no.
CLV620 Mid Range
Cable
Front
Line scanner CLV620-0000 1040288
Raster scanner CLV620-1000 1041548
Side (105°)
Line scanner CLV620-2000 1041550
Raster scanner CLV620-3000 1041552
Ethernet
Front
Line scanner CLV620-0120 1041547
Raster scanner CLV620-1120 1041549
Side (105°)
Line scanner CLV620-2120 1041551
Raster scanner CLV620-3120 1041553
