BAR CODE SCANNERS CLV64x
Detailed technical data
Features
CLV640 Standard Density CLV642 High Density
Light source
Visible red light (655 nm)
MTBF
40,000 h
Laser class
2 (EN 60825-1 (A2:2001-03), IEC 60825-1 : 2007-03, Ed. 2.0)
Field of view
≤ 50°
Scanning frequency
400 Hz ... 1,200 Hz
Code resolution
0.2 mm ... 1 mm 0.15 mm ... 0.25 mm
Reading distance (at code resolution)
Front 60 mm ... 840 mm (1 mm) 30 mm ... 345 mm (0.25 mm)
Side 44 mm ... 738 mm (1 mm) –
Oscillating mirror 45 mm ... 755 mm (1 mm) –
Raster height, number of lines, at distance
15 mm, 8, 200 mm
15 mm, 8, 185 mm
(depending on type)
–
Oscillating mirror functions
Fixed (adjustable position), oscillating (variable or xed amplitude), one shot
Oscillation frequency 0.5 Hz ... 6.25 Hz
Angle of deection –20° ... 20°
Performance
Bar code types
All current code types, Code 39, Code 128, Code 93, Codabar, GS1-128 / EAN 128,
UPC / GTIN / EAN, Interleaved 2 of 5, Pharmacode, GS1 DataBar, Telepen, MSI/Plessey
Print ratio
2:1 ... 3:1
No. of codes per scan
1 ... 20 (Standard decoder)
1 ... 6 (SMART decoder)
No. of codes per reading interval
1 ... 50 (auto-discriminating)
No. of characters per reading interval
5,000
500 (for multiplexer function in CAN operation)
No. of multiple readings
1 ... 99
Interfaces
Serial (RS-232, RS-422/485)
l, AUX (only RS-232)
Function Host, AUX
Data transmission rate 2,400 Baud ... 115 kBaud, AUX: 57.6 kBaud
Ethernet
– / l (depending on type)
Function Host, AUX
Data transmission rate 10/100 Mbit
Protocol TCP/IP, EtherNet/IP, PROFINET, PROFINET Dual Port (optional via external connection module
CDF600-2), EtherCAT (optional via external connection module CDF600)
(depending on type)
CAN bus
l
Function SICK CAN sensor network (Master/Slave, Multiplexer/Server)
Data transmission rate 20 kbit/s ... 1 Mbit/s
Protocol CANopen, CSN (SICK CAN Sensor Network)
PROFIBUS DP
l, optional via external connection module (CDF600-2)
DeviceNet
l, optional via external connection module (CDM + CMF)
A
B
C
D
E
F
H
I
J
K
L
M
N
O
P
Q
R
S
T
