SICK CLV6 Series User Manual

CLV6 SERIES | SICK 8016144/2013-09-19
Subject to change without notice
44
CLV64x BAR CODE SCANNERS
Switching inputs
Cable 4 (“Sensor 1”, “Sensor 2”, 2 inputs via optional CMC600 in CDB620/CDM420)
Ethernet 3 (“Sensor 1”, 2 inputs via optional CMC600 in CDB620/CDM420)
Switching outputs
Cable 4 (“Result 1”, “Result 2”, 2 outputs via optional CMC600 in CDB620/CDM420)
Ethernet 2 (via CMC600 in CDB620/CDM420)
Reading pulse
“Sensor 1” switching input, non-powered, serial interface, auto pulse, CAN
Optical indicators
6 LEDs (Ready, Result, laser, Data, CAN, LNK TX, Bar graph for displaying the reading rate
percentage (10 LEDs))
Acoustic indicators
Beeper/buzzer (can be switched off, can be allocated as a result indication function)
Control elements
2 buttons (choose and start/stop functions)
Memory card
MicroSD memory card (ash card) 512 MB, optional
Mechanics/electronics
Electrical connection
Cable 1 15-pin D-Sub HD male connector (0.9 m)
Ethernet 2 M12 cylindrical connectors (12-pin male connector, 4-pin female connector) on swivel con-
nector
Operating voltage
18 V DC ... 30 V DC
Power consumption
5.5 W / 6.5 W (depending on type)
Housing
Die-cast aluminum
Housing color
Light blue (RAL 5012)
Enclosure rating
IP 65 (EN 60529)
Protection class
III (EN 61140)
Weight
Cable 320 g ... 420 g, with connecting cable (depending on type)
Ethernet 250 g ... 350 g, without connecting cable (depending on type)
Dimensions
Front 61 mm x 96 mm x 38 mm
1)
Side 80 mm x 96 mm x 38 mm
1)
Oscillating mirror 95 mm x 96 mm x 41 mm
1)
1)
Swivel connector is 15 mm longer with Ethernet model.
Ambient data
Electromagnetic compatibility (EMC)
EN 61000-6-3 (2001-10) / EN 61000-6-2:2005
Vibration resistance
EN 60068-2-6 (1995)
Shock resistance
EN 60068-2-27 (1993)
Ambient operating temperature
0 °C ... +40 °C
Storage temperature
–20 °C ... +70 °C
Permissible relative humidity
90 %, non-condensing
Ambient light safety
2,000 lx, on bar code
Bar code print contrast (PCS)
≥ 60 %
