BAR CODE SCANNERS CLV65x
Detailed technical data
Features
CLV650 Standard Density CLV651 Low Density
Light source
Visible red light (658 nm)
MTBF
40,000 h
Laser class
2 (EN 60825-1 (A2:2001-03), IEC 60825-1 : 2007-03, Ed. 2.0)
Field of view
≤ 50°
Scanning frequency
600 Hz ... 1,000 Hz
Code resolution
0.25 mm ... 1 mm 0.5 mm
Reading distance (at code resolution)
Front 140 mm ... 1,625 mm (1 mm) 170 mm ... 930 mm (0.5 mm)
Oscillating mirror 125 mm ... 1,570 mm (1 mm) 155 mm ... 880 mm (0.5 mm)
Oscillating mirror functions
Fixed (adjustable position), oscillating (variable or xed amplitude), one shot
Oscillation frequency 0.5 Hz ... 6.25 Hz
Angle of deection –20° ... 20°
Performance
Bar code types
All current code types, Code 39, Code 128, Code 93, Codabar, GS1-128 / EAN 128,
UPC / GTIN / EAN, Interleaved 2 of 5, Pharmacode, GS1 DataBar, Telepen, MSI/Plessey
Print ratio
2:1 ... 3:1
No. of codes per scan
1 ... 20 (Standard decoder)
1 ... 6 (SMART decoder)
No. of codes per reading interval
1 ... 50 (auto-discriminating)
No. of characters per reading interval
5,000
500 (for multiplexer function in CAN operation)
No. of multiple readings
1 ... 99
Interfaces
Serial (RS-232, RS-422/485)
l, AUX (only RS-232)
Function Host, AUX
Data transmission rate 2,400 Baud ... 115 kBaud, AUX: 57.6 kBaud
Ethernet
– / l (depending on type)
Function Host, AUX
Data transmission rate 10/100 Mbit
Protocol TCP/IP, EtherNet/IP, PROFINET, PROFINET Dual Port (optional via external connection module
CDF600-2), EtherCAT (optional via external connection module CDF600)
(depending on type)
CAN bus
l
Function SICK CAN sensor network (Master/Slave, Multiplexer/Server)
Data transmission rate 20 kbit/s ... 1 Mbit/s
Protocol CANopen, CSN (SICK CAN Sensor Network)
PROFIBUS DP
l, optional via external connection module (CDF600-2)
DeviceNet
l, optional via external connection module (CDM + CMF)
Switching inputs
Cable 4 (“Sensor 1”, “Sensor 2”, 2 inputs via optional CMC600 in CDB620/CDM420)
Ethernet 3 (“Sensor 1”, 2 inputs via optional CMC600 in CDB620/CDM420)
Switching outputs
Cable 4 (“Result 1”, “Result 2”, 2 outputs via optional CMC600 in CDB620/CDM420)
Ethernet 2 (via CMC600 in CDB620/CDM420)
