CLV6 SERIES | SICK 8016144/2013-09-19
Subject to change without notice
52
CLV65x BAR CODE SCANNERS
Reading pulse
“Sensor 1” switching input, non-powered, serial interface, auto pulse, CAN
Optical indicators
6 LEDs (Ready, Result, laser, Data, CAN, LNK TX, Bar graph for displaying the reading rate
percentage (10 LEDs))
Acoustic indicators
Beeper/buzzer (can be switched off, can be allocated as a result indication function)
Control elements
2 buttons (choose and start/stop functions)
Memory card
MicroSD memory card (ash card) 512 MB, optional
Mechanics/electronics
Electrical connection
Cable 1 15-pin D-Sub HD male connector (0.9 m)
Ethernet 2 M12 cylindrical connectors (12-pin male connector, 4-pin female connector) on swivel con-
nector
Operating voltage
18 V DC ... 30 V DC
Power consumption
8.5 W / 9.5 W (depending on type)
Housing
Die-cast aluminum
Housing color
Light blue (RAL 5012)
Enclosure rating
IP 65 (EN 60529)
Protection class
III (EN 61140)
Weight
Cable 320 g, with connecting cable
Ethernet 250 g, without connecting cable
Dimensions
Front 61 mm x 96 mm x 38 mm
1)
Oscillating mirror 95 mm x 96 mm x 41 mm
1)
1)
Swivel connector is 15 mm longer with Ethernet model.
Ambient data
Electromagnetic compatibility (EMC)
EN 61000-6-3 (2001-10) / EN 61000-6-2:2005
Vibration resistance
EN 60068-2-6 (1995)
Shock resistance
EN 60068-2-27 (1993)
Ambient operating temperature
0 °C ... +40 °C
Storage temperature
–20 °C ... +70 °C
Permissible relative humidity
90 %, non-condensing
Ambient light safety
2,000 lx, on bar code
Bar code print contrast (PCS)
≥ 60 %
